Sesamo PROSWING - Page 28

PROSWING(M)
Operating instruction
28
ID of the-
parameter
Description Adjustment
DEFAULT
setting
12
Lock closing force RANGE: 0(min) ÷ 9(max) 5
13
Conditions Single/Double
0 = Single
1 = Double Master
2 = Double Slave
0
14
Block by motor on closed door according
the selected logic
0 = DDA opening
1 = One Radar
2 = Two Radars
3 = One Radar and Two Radars
1
15
Auxiliary input configuration 1
0 = DDA opening
1 = Emergency opening
2 = Interlock door with priority
3 = Interlock door without priority
4 = Feedback lock release
5 = Command lock release
6 = Command Single on Double door
0
16
Auxiliary input configuration 2
0 = DDA opening
1 = Emergency opening
2 = Interlock door with priority
3 = Interlock door without priority
4 = Feedback lock release
5 = Command lock release
6 = Command Single on Double door
1
17
Auxiliary output configuration 1
0 = Monitoring of the sensors
1 = Interlock
2 = Stop open condition
3 = Stop closed condition
4 = Failure
5 = Ripetizione comando serratura
0
18
Auxiliary output configuration 2
0 = Monitoring of the sensors
1 = Interlock
2 = Stop open condition
3 = Stop closed condition
4 = Failure
5 = Ripetizione comando serratura
1
19
MultiMaster
0 = No managing Multimaster,
1 ÷ 15 Keynote for MultiMaster connections
0
20
Opening safety sensor exclusion
Angle opening safety exclusion
RANGE: 0 ÷ 40% of total angle opening
30
21
Phase displacement in opening for double
door
RANGE: 0 - 100 displacement in opening unit of
100 ms (0=syncronized)
0
22
Phase displacement in closing for double
door
RANGE: 0 - 100 displacement in closing unit of
100 ms (0=syncronized)
0
23
Polarità ingresso Safe Open
0 = NO (Normally Open)
1 = NC (Normaly Close)
1
24
Polarità ingresso Safe Close
0 = NO (Normally Open)
1 = NC (Normaly Close)
1
25
Polarità ingresso Key
0 = NO (Normally Open)
1 = NC (Normaly Close)
1
26
Polarità ingresso Start 1
0 = NO (Normally Open)
1 = NC (Normaly Close)
0
27
Polarità ingresso Start 2
0 = NO (Normally Open)
1 = NC (Normaly Close)
0
28
Polarità ingresso Aux In1
0 = NO (Normally Open)
1 = NC (Normaly Close)
0
29
Polarità ingresso Aux In2
0 = NO (Normally Open)
1 = NC (Normaly Close)
0
