Installation Wiring/Light
______________________________________________________________________________
MillipaK 4QPM Controller Manual Page 10 13/08/03
NOTES:
The line and auxiliary contactors are wired to B+, on the switched side of the key-switch.
Pin 12 is available for 100mA supply, typically used for (but not limited to) accelerator modules.
Pins 13,14 & 15 are general-purpose suppression connections and may be used to suppress spikes
generated by contactors opening / closing. The internal configuration is shown below:
Pin 16 is used to select FLASH memory program update mode and should normally be left
unconnected.
