Commissioning Personalities Record
______________________________________________________________________________
MillipaK 4QPM Controller Manual Page 65 13/08/03
Personality Record
Range
Personality
New
Setting
Minimum Maximum
0.01 Armature Current Limit 50A ABR
1
1.01 Direction Change
Braking Level 5% 100%
1.02 Neutral Braking Level 0% 100%
1.03 Foot-brake Braking Level 0% 100%
2.01 Acceleration Delay 0.1s 5.0s
2.02 Drive Deceleration Delay 0.1s 10.0s
2.03 Direction Change Decel Delay 0.1s 10.0s
2.04 Neutral Deceleration Delay 0.1s 10.0s
2.05 Accelerator Zero V
2
0.00V 4.50V
2.06 Accelerator Full V
2,3
0.00V 4.50V
3.01 Creep Speed 0% 25%
5.01 Maximum Speed 0% 100%
5.02 Maximum Reverse Speed 0% 100%
6.01 Cutback Speed 1 0% 100%
7.01 Cutback Speed 2 0% 100%
8.01 I Cubed Lower Limit 0 254
8.02 I Cubed Upper Limit 1 255
9.01 Power Steer Timer 0s 60s
10.01 Seat Delay 0.1s 5.0s
11.01 Roll-Off Enable
OFF/ON
11.02 Walk Speed 0% 100%
11.03 Belly Delay 0.1s 5.0s
11.04 PSS Ramp Up Delay 0.1s
1.0s
11.05 PSS Timer 0.5s 10.0s
11.06 Line Contactor Dropout Timer 1s 60s
11.07 SRO Delay 0s 5s
11.08 Low Voltage Start Low V Cutout System Voltage
11.09 Low Voltage Cutout 14.5V Low V Start
11.10 High Voltage Start System Voltage High V Cutout
11.11 High Voltage Cutout High V Start 50.0V or 58.0V
4
11.12 Foot Brake Zero Volts 0.00V 4.50V
11.13 Foot Brake Full Volts 0.00V 4.50V
12.01 Chop Select OFF/ON/24V
12.02 SRO Enable OFF/ON
12.03 Control Mode TORQUE/SPEED
12.04 Seat Cuts Pump OFF/ON
12.05 Roll-Off Electro brake OFF/ON
12.06 Reverse Speed Limit OFF/ON
12.07 FS1 recycle on Dir Change OFF/ON
12.08 Dir Sw Seq Checking OFF/ON
12.09 Motor Thermal Protection OFF/ON
