MillipaK 4QPM Controller Manual Page 11 13/08/03
Calibrator
The Calibrator is a hand-held adjustment unit which can be used to configure and test the system.
The MillipaK is designed to work with the Calibrator currently in use with SEVCON's MOS90
system. See diagram below. The menu structure is shown in the Calibrator Map located near the
end of this manual.
CALIBRATOR
Sevcontrol
+
-
SELECT
i.8.8.8
Figure 4: MillipaK Calibrator
