Configuration System/Armature Current Limit
______________________________________________________________________________
MillipaK 4QPM Controller Manual Page 23 13/08/03
Armature Current Limit
The armature current limit personality is provided to allow the user to limit the maximum current
supplied to the motor to a value lower than the peak rating of the controller.
Immediate Armature Current Limit
Calibrator Menu Reference:
0.01
Minimum Maximum Step Size Typical Value
50A ABR 10A ABR
ABR – Armature Block Rating refers to the controller maximum peak current.
