8
Installation
Control cabinet installation
Product Manual – MOVIDRIVE
®
system
222
8.5.3 Top shield plate
1. Insert the shield plate [2] so that you can fasten it to the device housing [3] with the
screw [1].
5
4
3
2
1
5
4
3
2
1
[1]
[3]
[2]
27521510667
8.5.4 Shield plate at bottom of control unit
1. Insert the shield plate [2] so that you can fasten it with the screw [1] in the position
[3] shown in the figure.
X16
X15
[1]
[2]
[3]
27521507083
28487486/EN – 02/2019
