Technical data
Electronics data – signal terminals
Product Manual – MOVIDRIVE
®
system
47
2.5 Electronics data – signal terminals
Terminal designation Specification
General
Design According to IEC61131-2
Supply voltage
Port X5 External power supply 24V according to IEC61131
Connecting contacts
Plug connector
- 1 core: 0.25–2.5 mm
2
- 2 cores: 0.5–1.5 mm
2
(Twin-AEH)
1)
1) AEH: Conductor end sleeve
Digital inputs
Cycle time input 1ms / 500μs
Quantity
• 6 with MOVIDRIVE
®
system
• 8 with MOVIDRIVE
®
technology
Response time 100 μs plus cycle time
Assignment
X20: 1 – 6 DI00: "Output stage enable" fixedly assigned.
DI01 – DI05: Selection option, see parameter menu.
All inputs are suitable for touchprobe function. Latency period <
100 µs, max. 2 simultaneously.
DI04, DI05: HTL low-resolution encoder connection.
DI05: Primary frequency input.
X20: 7 – 8 Reserved
X20: 9 GND
Connecting contacts
Plug connector
- 1 core: 0.25–2.5 mm
2
- 2 cores: 0.5–1.5 mm
2
(Twin-AEH)
1)
1) AEH: Conductor end sleeve
Digital outputs
Cycle time output 1ms / 500μs
Quantity 4
Response time 175 μs plus cycle time
Output current I
max
= 50mA
Short-circuit protection Yes
Assignment
X21: 1 +24V supply voltage
Maximum output current = 50mA
X21: 2 – 5 DO00 – DO03: Selection option, see parameter menu.
X21: 6 GND
Connecting contacts
Plug connector
- 1 core: 0.25–2.5 mm
2
- 2 cores: 0.5–1.5 mm
2
(Twin-AEH)
1)
1) AEH: Conductor end sleeve
Brake control
Assignment
X10:DB0 DB00:
- Brake control
- Control braking contactor DC 24 V, max. 150mA
X10:GND GND
X10:TF1 Sensor input for temperature evaluation of the motor
Connecting contacts
Plug connector
MDX9_A-0020 – 0320-5_3-..
MDX9_A-0070 – 0290-2_3-..:
- One core: 0.25–2.5 mm
2
MDX9_A-0460-5_3-.. and newer
MDX9_A-0420-2_3-..: and newer
- One core: 0.25–2.5 mm
2
- Two cores: 0.5–1 mm
2
(Twin-AEH)
1)
1) AEH: Conductor end sleeve
Encoder input
X15:13 X15:13 DC 24V, I
max
= 500mA
X15:15 X15:15 DC 12 V, I
max
= 500mA
28487486/EN – 02/2019
2

SEW-Eurodrive MOVIDRIVE system Specifications

General

Category	Inverter
Series	MOVIDRIVE system
Output Voltage	0 - Input Voltage
Protection Class	IP20, IP65 (depending on model)
Type	Frequency Inverter
Output Current	Varies by model
Control Method	Sensorless vector control, V/f control
Communication Interfaces	CANopen
Safety	Safe Torque Off (STO), Safe Stop 1 (SS1)
Input Voltage	200-240V AC, 380-480V AC, 500-600V AC
