9.2.5 - BLIND DISTANCE
Position the cursor on DISTANCE 4mA, press ENTER to access.
Represent the “BLIND ZONE”
Input the desired value in order to avoid measures near the surface of the
sensor (if necessary).
The minimum value is 250mm (6m vers.) or 400mm (10m vers.)
Use UP ARROW and SCROLL to modify the value.
Press ENTER to confi rm.
LEFT ARROW to exit without changes
Default values: 250mm (range 6m) or 400mm (range 10m)
SET DISTANCE 4mA
SET DISTANCE 20mA
MEDIUM
FILTER COEFFICIENT
BLIND DISTANCE
ACTUAL LEV. 4mA
ACTUAL LEV. 20mA
RELAYS
►
0250 mm
BLIND DISTANCE
9.2.6 - ACTUAL LEV. 4mA
Position the cursor on ACTUAL LEV. 4mA, press ENTER to access.
Self distance learning function that is associated with the 4mA (lower val-
ue). Make sure that the level corresponds to 0%, ENTER to associate the
actual measure with 4mA output value;
OK TO CONFIRM .
LEFT ARROW to exit without changes.
SET DISTANCE 4mA
SET DISTANCE 20mA
MEDIUM
FILTER COEFFICIENT
BLIND DISTANCE
ACTUAL LEV. 4mA
ACTUAL LEV. 20mA
RELAYS
►
9.2.7 - ACTUAL LEV. 20mA
Position the cursor on ACTUAL LEV. 20mA, press ENTER to access.
Self distance learning function that is associated with the 20mA (upper
value). Make sure that the level corresponds to 100%, ENTER to associate
the actual measure with 20mA output value;
OK TO CONFIRM .
LEFT ARROW to exit without changes.
