SGM LEKTRA METER - 9.4.1.2-2 VALUE; 9.4.2 - LCD CONTRAST

Page 31 of 40
9.4.1.2 - 2 VALUE
Position the cursor on 2 VALUE, press ENTER to access.
Two values are displayed; it’s possible to choose which one is the prima-
ry and which is the secondary, each with a choice of 5 parameters.
With the SCROLL button you can select data to display.
Press ENTER to confi rm.
LEFT ARROW to exit without changes
1 VALUE
2 VALUES
►
PRIMARY VALUE
SECONDARY VALUE
►
METER - advanced confi guration
DISTANCE mm
LEVEL mm
LEVEL %
OUTPUT mA
TEMPERATURE °C
►
PRIMARY VALUE
SECONDARY VALUE
►
DISTANCE mm
LEVEL mm
LEVEL %
OUTPUT mA
TEMPERATURE °C
►
9.4.2 - LCD CONTRAST
Position the cursor on LCD CONTRAST, press ENTER to access.
it’s possible to adjust the contrast of LCD, simply increasing or decreasing
the value of a parameter from 0 to 63.
Use UP ARROW and SCROLL to modify the value.
Press ENTER to confi rm.
LEFT ARROW to exit without changes
Default value: 32
DISPLAY VALUES
LCD CONTRAST
WELCOME TEXT
►
32
LCD CONTRAST
