SGM LEKTRA METER - 8-QUICK SETUP; 8.1 - Quick Setup menu structure; 8.2 - QUICK SETUP MODE

Page 15 of 40
Quick Setup
Set Distance 4mA
Set Distance 20mA
Medium
Filter Coecient
Blind Distance
Display
RL1 Threshold
RL2 Threshold
Set Distance 4mA
0000 mm
Set Distance 20mA
0000 mm
Medium
>Liquids
Solids
Liquids Pipe
Filter Coecient
000
Blind Distance
0000 mm
RL1 Threshold
0000 mm
RL1 Threshold
0000 mm
Distance mm
Level mm
Level %
Output mA
Temperature °C
Parameter Default Values
6000mm (6mt max range)
10000mm (10mt max range)
Liquids
20
250mm (6mt max range)
400mm (10mt max range)
Distance mm
0mm (Disabled RL1)
0mm (Disabled RL2)
300mm (6mt max range)
500mm (10mt max range)
METER - quick setup
8-QUICK SETUP
8.2 - QUICK SETUP MODE
From “RUN” mode press ENTER to access the Quick Setup menu.
Select the parameters by moving the cursor with SCROLL, and confi rm with
ENTER; press LEFT ARROW to exit.
SET DISTANCE 4mA
SET DISTANCE 20mA
MEDIUM
FILTER COEFFICENT
BLIND DISTANCE
DISPLAY
RL1 THRESHOLD
RL2 THRESHOLD
►
4321
D
mm
8.1 - Quick Setup menu structure
