SGM LEKTRA METER - 9.3 DISPLAY menu; 9.4 - DISPLAY; 9.4.1 - DISPLAY VALUES; 9.4.1.1-1 VALUE

Page 30 of 40
METER - advanced confi guration
9.3 “DISPLAY” menu
DISPLAY DISPLAY VALUES
LCD CONTRAST
WELCOME TEXT
>1 VALUE
2 VALUES
1 VALUE
>2 VALUES
LCD CONTRAST
00
WELCOME TEXT
SGM-LEKTRA METER
DISTANCE mm
LEVEL mm
LEVEL %
OUTPUT mA
TEMPERATURE °C
>PRIMARY VALUE
SECONDARY VALUE
PRIMARY VALUE
>SECONDARY VALUE
DISTANCE mm
LIVEL mm
LIVEL %
OUTPUT mA
TEMPERATURE °C
9.4 - DISPLAY
From “RUN” mode, holding down UP ARROW, press ENTER to access
Position the cursor on DISPLAY and press ENTER
Select the parameters by moving the cursor with SCROLL and confi rm with
ENTER
DISPLAY VALUES
LCD CONTRAST
WELCOME TEXT
►
SETUP
DISPLAY
DIAGNOSTIC
SERVICE
INFO
►
9.4.1 - DISPLAY VALUES
Position the cursor on DISPLAY VALUES, press ENTER to access.
It’s possible to select if one value with big digits or two values are shown on
the display in “RUN” mode.
Select the parameters by moving the cursor with SCROLL and confi rm with
ENTER.
LEFT ARROW to exit without changes
DISPLAY VALUES
LCD CONTRAST
WELCOME TEXT
►
1 VALUE
2 VALUES
►
9.4.1.1 - 1 VALUE
Position the cursor on 1 VALUE, press ENTER to access.
Only one value is displayed; it’s possible to choose from 5 parameters.
With the SCROLL button you can select data to display.
Press ENTER to confi rm.
LEFT ARROW to exit without changes
1 VALUE
2 VALUES
►
DISTANCE mm
LEVEL mm
LEVEL %
OUTPUT mA
TEMPERATURE °C
►
4321
D
mm
