SGM LEKTRA METER - 9.2.8.1.3 - DELAY; 9.2.8.1.4 - SAFETY; 9.2.8.1.5 - ENABLE;DISABLE; 9.2.8.1.6 - MIN;MAX HYSTERESIS mm

Page 27 of 40
9.2.8.1.3 - DELAY
Position the cursor on DELAY, press ENTER to access.
It’s possible to set the activation delay for the selected relay, from 0 to 99
sec.
Use UP ARROW and SCROLL to modify the value.
Press ENTER to confi rm.
LEFT ARROW to exit without changes
Default value: 00s
00 s
DELAY
VALUE
MIN/MAX
DELAY
SAFETY
ANABLE/DISABLE
MIN/MAX HYSTERESIS
►
METER - advanced confi guration
9.2.8.1.4 - SAFETY
Position the cursor on SAFETY, press ENTER to access.
A “safety alarm” provides a “closed” contact with relay energized in nor-
mal condition (no alarm), the contact switches to “open”:
- Alarm condition (eg overcoming MAX);
- In power failure case.
With the SCROLL button you can select the alarm mode.,
Press ENTER to confi rm.
LEFT ARROW to exit without changes
Default value: YES
VALUE
MIN/MAX
DELAY
SAFETY
ANABLE/DISABLE
MIN/MAX HYSTERESIS
►
NO
YES
►
9.2.8.1.5 - ENABLE/DISABLE
Position the cursor on ENABLE/DISABLE, press ENTER to access.
Select ENABLE to activate relay threshold.
Select DISABLE to not activate relay threshold.
With the SCROLL button you can select the operation mode.
Press ENTER to confi rm.
LEFT ARROW to exit without changes
Default value: DISABLE
VALUE
MIN/MAX
DELAY
SAFETY
ANABLE/DISABLE
MIN/MAX HYSTERESIS
►
9.2.8.1.6 - MIN/MAX HYSTERESIS mm
Position the cursor on MIN/MAX HYSTERESIS mm, press ENTER to
access.
It’s possible to input the threshold hysteresis.
Use UP ARROW and SCROLL to modify the value.
Press ENTER to confi rm.
LEFT ARROW to exit without changes
Default value: 40mm
VALUE
MIN/MAX
DELAY
SAFETY
ANABLE/DISABLE
MIN/MAX HYSTERESIS
►
DISABLE
ENABLE
►
040 mm
MIN/MAX HYSTERESIS mm
