SGM LEKTRA METER - 9.6.5.1-DISPLAY VALUES; 9.6.5.2 - RESET VALUES; 9.6.6-OUTPUT SIMULATION

Page 35 of 40
9.6.5.1 - DISPLAY VALUES
Position the cursor on DISPLAY VALUES, press ENTER to access.
Displays the max. and min. distance measured from power on.
LEFT ARROW to exit.
NB - The peak values stored are erased every time the METER turns-off
DISPLAY VALUES
RESET VALUES
►
MAX 0000mm
MIN 0000mm
PEAK VALUES
METER - advanced confi guration
9.6.5.2 - RESET VALUES
Position the cursor on RESET VALUES, press ENTER to access.
LEFT ARROW to return to the previous menu
DISPLAY VALUES
RESET VALUES►
9.6.6 - OUTPUT SIMULATION
WARNING - entering in the SIMULATION function, the current output is not
in function of the level measurement. To restore the current as a measured
level function, press the LEFT ARROW button 3 times (RUN mode)
Position the cursor on OUTPUT SIMULATION, press ENTER to access.
It’s possible to force the analog output to a desired value, from 3,5 to
21mA.
Use UP ARROW and SCROLL to modify the value.
LEFT ARROW to return to the previous menu.
ALARM CONFIGURATION
MEASURE STATUS
FROZEN GAIN
MAX GAIN TH.
PEAK VALUES
OUTPUT SIMUL.►
04.0mA
OUTPUT SIMUL.
