Shark UL User Manual

Page 2-3
Flight manual UL aircraft
2.4. ENGINE
SHARK is powered by 100HP ROTAX 912 ULS engine.
Airplane
Engine type
SHARK
ROTAX 912 ULS
Max. take-off power (kW)
73,5
Max. continuous power (kW)
69
Max. engine speed (5 min)
5 800 ot/min
Max. engine speed (continuous)
5 500 ot/min
Max. cylinder head temperature (°C)
150
Max. oil temperature (°C)
140
Oil pressure - minimum (bar)
0,8 below 3500 rpm
2,0 above 3500 rpm
Oil pressure: maximum, cold start
only (bar)
7
Oil pressure: normal operation (bar)
2,0 – 5,0
Fuel pressure: min-max (bar)
0,15 – 0,4
Operation range of outside
temperature
-25°C
+ 50°C
For more details see Operator’s Manual for all versions of Rotax 912
supplied with the engine.
WARNING:
Flying this aircraft must always be done with the possibility of a
safe landing due to loss of engine power.
The pilot is fully responsible for consequences of such failure
