7.8. PROPELLER
Shark can be equipped by different propellers:
DUC SWIRL - 3 blade, on the ground adjustable
Woodcomp SR 3000 2WN - 2 blade, in flight electrically adjustable
Woodcomp KW20W - 2 blade, in flight hydraulically adjustable
Neuform TXR2-V-70 - 2 blade, in flight electrically adjustable
7.8.1. DUC SWIRL 3 blade, on the ground adjustable
propeller, diameter 1680 mm
Weight of this 3 blade propeller is 4,5 kg. It has carbon core, same as DUC
FC WINDSPOON propeller, resistant to heavy loads.
This propeller is simple, lightweight, robust, with a stainless steel leading
edge. It achieves high cruising speeds, but it is less efficient during
take-off. It is therefore not suitable for short grassland airports.
Sheet settings are more laborious. Recommended angle is 24º.
