7.8.4. Neuform TXR2-V-70
Neuform TXR2-V-70 is electrically or hydraulically in flight adjustable
propeller with two composite blades. The blades are made of glass-fiber
and are hollow. Root of blade is duralumin. Outside part of blade leading
edge is casted of plastic material with improved resistance to abrasion.
Servo controling the angle of the blades is located on the engine gearbox.
Mechanical stops and micro switches of maximum and minimum angle of
attack are situated on the servo brackets.
The minimum angle of attack is set as mechanical stop by spacer rings
during propeller assembly.
Blade setup provides control unit FLYBOX.
