7.2.2. Main undercarriage
Legs of main undercarriage are welded from steel tubes and sheets, the
main parts are hardened for better resistance required by 600kg MTOW.
Legs are hinged in two brackets with mounted bearings SKF between
centre-wing beams. Legs are retracted to fuselage bays.
Main joints are equipped by bronze bearings with grease-caps.
