155
Appendix
z
Battery life is short
y
Make sure the handset is not left for a long time outside the
service area. Outside the service area, since radio waves are
searched to make communication available, more electric
power than usual is used.
When the handset keeps out of service, turn power off or set
Airplane mode.
P. 43 “Turning power off” , P. 110
“Network & internet”
y
The battery life depends on the usage environment and
deterioration level.
P. 161 “Main specifications”
y
The internal battery is a consumable product. Battery life per
charge is gradually reduced every time the battery is charged.
Contact the support phone number listed on the Warranty
Card if the battery life becomes extremely shorter than at the
time of purchase even after fully charged.
P. 24
“Replacing the built-in battery”
y
End apps which are not in use.
y
Set wireless functions which are not in use to OFF.
P. 110
“Wi-Fi” , P. 144 “Using Bluetooth function
y
Conserve the battery power by using Battery Saver.
P. 118 “Battery Saver”
z
Not activated by touching or pressing keys
y
Make sure the handset is not turned off.
P. 43 “Turning
power on
z
Screen response is slow when touching or pressing keys
y
This may happen when a great deal of data is saved on the
handset, when a large amount of data is being transferred
between the handset and the microSD Card, etc.
P. 125
“Storage
z
nanoSIM Card is not recognized
y
Is the nanoSIM Card inserted facing right direction?
P. 36 “nanoSIM Card”
z
Clock is incorrect
y
Clock may become incorrect if the power is left turned on for a
long time. Make sure [Automatic date & time] is set to ON and
turn the power on again in a location with good signal
conditions.
P. 138 “Date & time
z
Handset operation is unstable
y
The apps installed on the handset after purchase may become
a cause. If you can improve the symptoms by activating the
handset with the safe mode set, you may be able to improve
the symptoms by uninstalling the installed apps.
* Safe mode is a function to start up the handset in a state
close to that at the time of purchase.
y
For activating the safe mode
Turn the power on again when the power is turned off, then
keep pressing
2
on the screen during activation until the
lock screen of the touch panel is displayed.
* Alternatively,
9
while the power is turned on
(for at least 2 seconds)
touch and hold [Power off]
[OK]
to activate the safe mode.
* When the safe mode is activated, [Safe mode] is
displayed at the bottom left of the screen.
* To deactivate the safe mode, turn the power on again.
y
Back up the necessary data in advance before using the
safe mode.
y
Depending on the widget, it may disappear.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Sharp Aquos R3 and is the answer not in the manual?

Sharp Aquos R3 Specifications

General IconGeneral
Panel typeIGZO
Screen shapeFlat
Pixel density554 ppi
Display diagonal6.2 \
Touch technologyMulti-touch
Touchscreen typeCapacitive
Display resolution3120 x 1440 pixels
Maximum refresh rate120 Hz
Fingerprint resistantYes
Gorilla Glass versionGorilla Glass 5
Display number of colors16 million colors
High Dynamic Range (HDR) technologyHigh Dynamic Range 10+ (HDR10 Plus)
Processor cores1
Processor familyQualcomm Snapdragon
Coprocessor cores4
Processor frequency2.84 GHz
Coprocessor frequency1.8 GHz
Processor lithography7 nm
Processor architectureARM Cortex-A76
RAM typeLPDDR4X
RAM capacity6 GB
RAM clock speed1866 MHz
Compatible memory cardsMicroSD (TransFlash), MicroSDHC, MicroSDXC
Maximum memory card size512 GB
Internal storage capacity128 GB
Flash typeLED
Sensor typeBSI CMOS
ISO sensitivity100, 125, 160, 200, 250, 320, 400, 500, 640, 800, 1000, 1250, 1600, 2000, 2200, 2250, 2500, 3200
Rear camera typeDual camera
Front camera typeSingle camera
Maximum frame rate30 fps
Video recording modes1080p
Rear camera resolution4608 x 3456 pixels
Rear camera aperture number2.4
Second rear camera pixel size1.4 µm
Rear camera resolution (numeric)20 MP
Front camera resolution (numeric)16 MP
Second rear camera aperture number1.7
Rear camera field of view (FOV) angle78 °
Second rear camera resolution (numeric)12 MP
4G standardLTE-TDD & LTE-FDD
2G standardsEDGE, GPRS, GSM
3G standardsHSPA+, UMTS
SIM card typeNanoSIM
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version5.0
3G bands supported800, 850, 2100 MHz
4G bands supported700, 800, 850, 900, 1700, 1800, 2100, 2300, 2500, 2600 MHz
Bluetooth profilesA2DP, AVRCP, DUN, FTP, HID, HOGP, HSP, OPP, PAN, PBAP, SPP
SIM card capabilityHybrid Dual SIM
2G bands (primary SIM)850, 900, 1900 MHz
2G bands (secondary SIM)850, 900, 1800, 1900 MHz
Mobile network generation4G
Graphics cardAdreno 640
Personal info management (PIM)Alarm clock, Calculator, Calendar, File manager
USB version3.2 Gen 1 (3.1 Gen 1)
USB connector typeUSB Type-C
Headphone connectivity3.5 mm
Form factorBar
Product colorBlack
International Protection (IP) codeIPX5, IPX8
Multimedia Messaging Service (MMS)Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
FM radioNo
Audio systemDolby Atmos
Supported video modes240p, 360p, 480i, 480p, 525i, 540p, 576i, 576p, 625i, 720i, 720p, 768p, 960p, 1024p, 1035i, 1080i, 1080p
Audio formats supportedAAC, AAC+, AMR, AMR-NB, AMR-WB, FLAC, MIDI, MP3, OGA, OGG, OPUS, WAV, WMA
Video formats supported3GP, AVI, DIVX, FLV, H.263, H.264, H.265, MKV, MOV, MP4, VP9, WEBM, WMV, XVID
PlatformAndroid
App distribution platformGoogle Play
Operating system installedAndroid 9.0
Talk time (2G)14.5 h
Talk time (3G)30 h
Battery capacity3200 mAh
Standby time (2G)580 h
Standby time (3G)685 h
Standby time (4G)600 h
Weight and Dimensions IconWeight and Dimensions
Depth8.9 mm
Width156 mm
Height74 mm
Weight185 g
