78
GENERAL INFORMATION
PAPER
Types and sizes of copy paper
Types and sizes of copy paper which can be fed from the paper trays are shown below.
For paper acceptable for feeding from the bypass tray, see page 36.
●
A5 and 5-1/2" x 8-1/2" copy papers cannot be fed from any tray except the uppermost tray. (including
trays in optional paper feed units)
●
B5 paper cannot be set for paper tray 2.
●
Special papers including transparency film must be fed through the bypass tray.
Loading copy paper
To save space, this copier has been designed with adjustable front-loading trays, which are easily
opened for paper loading. For best results, use only SHARP recommended paper.
The message "TRAY<✻>: Add paper." will be displayed when there is no copy paper in the selected
paper feed station.
When the selected paper tray is not installed or is improperly installed, "Push paper tray <✻> into the
machine until it latches." will be displayed. Install it or push it back firmly into place.
NOTE:
When the paper size is changed in a paper tray, the size of the paper must be entered as
described on page 80. If not, the machine will stop copying and the message "Load <✻✻> paper
into tray <✻>." will appear in the display. In this case, load the paper requested in the message.
<✻> : paper tray number
<✻✻>: paper size to be set
1
Pull out the paper tray until it stops.
2
Squeeze the lock lever of the front guide and slide the front guide to
match the width of the paper.
Size Weight Capacity (80 g /m
2
(21 lb.) paper)
A5 to A3 56 to 80 g/m
2
(15 lbs. to 21 lbs.) 500 sheets
5-1/2" x 8-1/2" to 11" x 17"
Front guide
Left guide
