Sharp FO-2080 User Manual

14
INSTALLING THE TD (TONER/DEVELOPER) CARTRIDGE
1
Open the bypass tray, and
then open the side cover.
2
Remove the CAUTION tape from the front cover and remove the
two protective pins from the fusing machine by pulling the
strings upward one at a time.
3
Press gently on both sides of
the front cover to open the
cover.
4
Remove the TD (Toner/Developer) cartridge from the bag. Remove
the protective paper. Hold the cartridge on both sides and shake it
horizontally four or five times. Hold the tab of the protective cover
and pull the tab to your side to remove the cover.
CAUTION tape
Protective pins
4 or 5 times
!FO-2080.book 14 ページ ２００９年５月１５日 金曜日 午前１０時４２分

Sharp FO-2080 Specifications

General

Brand	Sharp
Model	FO-2080
Category	All in One Printer
Language	English
