TROUBLESHOOTING AND MAINTENANCE
83
8
3
Gently pull the TD (Toner/Developer)
cartridge out while pressing the lock
release button.
4
Remove the TD (Toner/Developer) cartridge from the bag.
Remove the protective paper. Hold the cartridge on both sides
and shake it horizontally four or five times. Hold the tab of the
protective cover and pull the tab to your side to remove the
cover.
5
While pushing the lock release
button, gently insert the TD (Toner/
Developer) cartridge until it locks
into place.
• After removing the TD cartridge, do not shake it or tap on it. Doing so
may cause toner to leak from the cartridge. Put the old cartridge
immediately in the bag contained in the box of the new cartridge.
• Dispose of the old TD cartridge in accordance with local regulations.
Lock release button
Note
4 or 5 times
Lock release button
!FO-2080.book 83 ページ ２００９年５月１５日 金曜日 午前１０時４２分
To Next Page
