APPENDIX
92
*
1
When making multiple duplex copies, the copy speed will vary based on the
environment conditions.
*
2
The first-copy time is measured after the power save indicator turns off following
power on, using the document glass with the polygon rotating in the copy ready
state and "LSU SETTING" set to ON in the user programs (8-1/2" x 11", paper fed
from paper tray).
The first-copy time may vary depending on machine operating conditions and
ambient conditions such as temperature.
The time from power on until the first copy is output varies depending on the
installation site and the state of the machine in use.
*
3
The warm-up time may vary depending on machine operating conditions and
ambient conditions such as temperature.
*
4
Not including TD and drum cartridges.
Fusing system Heat rollers
Developer system Magnetic brush development
Light source
Cold cathode fluorescent lamp
(CCD: 3 components; R, G, and B)
Resolution
Scan: 600 x 300 dpi Output: 600 x 600 dpi(AUTO/TEXT mode)
Scan: 600 x 600 dpi Output: 600 x 600 dpi(PHOTO mode)
Gradation 256 tones (8 bits)
Power supply 120 V, 60 Hz, 8.0 A
Power consumption Max. 1.0 kW
Space requirements
(with trays extended)
31.6" (W) x 17.6" (D) (802 mm (W) x 445 mm (D))
Weight*
4
Approx. 50.6 lbs. (22.9 kg)
Dimensions
20.4" (W) x 17.6" (D) x 18.1" (H)
(518 mm (W) x 445 mm (D) x 459 mm (H))
Operating
conditions
Temperature: 50°F to 86°F (10°C to 30°C)
Humidity: 20% to 85%
Acoustic noise
emission
(measurement
according to
ISO7779)
Sound power level Lw
A
Printing mode(continuous printing): 6.1 B
Standby mode: 3.0 B
Sound pressure level Lp
A (actual measurement)
Printing mode (Bystander positions): 47 dB (A)
Printing mode (Operator position): 50 dB (A)
Standby mode (Bystander positions): 15 dB (A)
Standby mode (Operator position): 16 dB (A)
