MX-5111N IC card reader 32 – 5
C. Attach the operation panel upper cover
D. Connect the connector of the IC card reader to
the connector of the machine
E. Turn ON the power of the main unit
1) Connect the power plug of the machine to the power outlet,
and turn ON the main power switch and the operation panel
power switch.
F. System setting modification
IC card reader device registration
1) Device registration
a) Enter the card reader setting menu as shown below.
System SettingsUser ControlCard Reader Device
Registration
b) Press [Read] button.
c) Disconnect the connector which links the machine and the
IC card reader, and then insert it back.
d) Press [OK] button.
e) Check to confirm that values are displayed on "Product
ID" and "Vender ID".
f) Press [SUBMIT] button, and check to confirm that the suc-
cess dialog message is displayed.
To Next Page
