MX-5111N Dehumidifying heater 3 – 1
MX-5111N
Service Manual
[3] Dehumidifying heater
1. Parts included
Kit name Kit part code
Package
part No.
Description Part code Q'ty Remarks
Heater electric
component kit
DKIT-0391FCZZ 1 Dehumidifier heater switch QSW-C9294QCZZ 1
2 Label for heater switch TLABZ5256FCZZ 1
3 Supporter LSUPP0118FCPZ 5
4 WH PWB CPWBF1675FC338 1
5 AC-WH harness 1 DHAI-3755FCZ1 1
– AC-WH harness 2 DHAI-3756FCZZ 1 Not used in this model
Heater kit DKIT-0385FCZZ
(120V series)
DKIT-0386FCZZ
(230V series)
6 Heater (120V series) RHETP0131FCPZ 1
Heater (230V series) RHETP0132FCPZ
7 Heater mounting plate LPLTM6089FCZZ 1
8 Screw (M3x6 S-tight) XHBS730P06000 3
9 T-Heater cover PCOVP1654FCZ2 1
10 Caution label (For high temperature) TCAUH1035FCZZ 1
11 Screw (M3x5 S-tight) XHBS730P05000 1
12 Omega lock LHLDW1334FCZZ 1
Scanner heater kit DKIT-0383FCZZ
(120V series)
DKIT-0384FCZZ
(230V series)
13 Scanner heater (120V series) RHETP0129FCPZ 1
Scanner heater (230V series) RHETP0130FCPZ
14 Heater fixing plate LPLTM6923FCZZ 1
15 Banding band LBNDJ0013FCZ1 2
16 Clamp LHLDW7011XCZZ 5
17 Screw (M3x4 Round-tipped) LX-BZ1041FCZZ 2
18 Screw (M4x6 Bind machine screw) XBBS740P06000 1
19 Snap band LBNDJ0043FCZZ 1
Desk heater kit DKIT-0429FCZZ
(120V series)
DKIT-0429FC11
(230V series)
20 Desk heater (120V series) RHETP0144FCZZ 1
Desk heater (230V series) RHETP0139FCZZ
21 Heater heat sink PRDAR0087FCZZ 1
22 Screw (M3x4 S-tight) XHBS730P04000 4
23 Desk heater mounting plate LPLTM6021FCZZ 1
24 Edge wire saddle LHLDW1503FCZZ 1
25 Screw (M3x6 S-tight) XHBS730P06000 2
26 Caution label (For high temperature) TCAUH1035FCZZ 1
27 Desk heater harness (120V series) DHAI-4829FCZZ 1
Desk heater harness (230V series) DHAI-4845FCZZ
28 Screw (M4x8 K) XBPS740P08K00 1
29 Mini clamp LHLDW1225FCZZ 1
LCC heater kit DKIT-0424FCZZ
(120V series)
DKIT-0424FC11
(200V series)
1 Heater harness (120V series) DHAI-4742FCZZ 1
Heater harness (200V series) DHAI-3974FCZZ 1
2 Snap band LBNDJ0043FCP1 1
3 AC cord fixer LFIX-0016FCZZ 1
4 Protect sheet PFLT-0067FCP1 1
5 Connector cover A PCOVP2149FCZZ 1
6 Connector cover B PCOVP2150FCZZ 1
7 Heater (120V series) RHETP0145FCZZ 1
Heater (200V series)
RHETP0121FCZZ 1
8 Screw (M4 x 8K) XBPS740P08K00 1
9 Screw (M3 x 4) XHBS730P04000 1
10 Screw for EL connector LX-BZ1119FCZZ 1
11 Screw (M4 x 28K) XBPS740P28KS0 2
12 Screw (M3 x 20) XBBS730P20000 3
13 Screw (M4 x 10) XHBS740P10000 1
14 Nut (M3 = 2.4) 0EUNZ3024SCPE 3
