MX-5111N CONFIGURATION 1 – 1
MX-5111N
Service Manual
[1] CONFIGURATION
1. System diagram
MX-5110N/5111N/5112N
MX-4110N/4111N/4112N
DIGITAL FULL COLOR
MULTIFUNCTIONAL SYSTEM
MX-DE15
STAND/1x500 SHEET
PAPER DRAWER
MX-DE16
STAND/2x500 SHEET
PAPER DRAWER
MX-FNX9
FINISHER
MX-FN10
SADDLE STTICH FINISHER
MX-FN18
SADDLE STTICH FINISHER
MX-FN11
FINISHER
MX-RB11
PAPER PASS UNIT
MX-LC11
LARGE CAPACITY TRAY
MX-PNX1A/B/C/D
PUNCH MODULE
MX-RP14
REVERSING SINGLE PASS
FEEDER
MX-EF10
DUPLEX SINGLE PASS
FEEDER
MX-PNX5A/B/C/D
PUNCH MODULE
MX-PNX6A/B/C/D
PUNCH MODULE
MX-TU13
EXIT TRAY CABINET
MX-TRX2
EXIT TRAY UNIT
MX-DS15
STAND
MX-FWX1
INTERNET FAX EXPANSION
KIT
MX-US50
SHARPDESK 50 LICENSE
KIT
MX-USA0
SHARPDESK 100 LICENSE
KIT
MX-UN50A
Sharp OSA Network Scanner
Tool 50 License Kit
MX-UN1HA
Sharp OSA Network Scanner
Tool 100 License Kit
MX-AMX1
APPLICATION
INTEGRATION MODULE
MX-AMX2
APPLICATION
COMMUNICATION MODULE
MX-AMX3
EXTERNAL ACCOUNT
MODULE
MX-PK11
PS3 EXPANSION KIT
MX-PUX1
XPS EXPANSION KIT
MX-PF10
BARCODE FONT KIT
AR-SU1
STAMP UNIT
MX-FX11
FACSIMILE EXPANSION KIT
MX-EB11
ENHANCED COMPRESSION
KIT
MX-US10
SHARPDESK 10 LICENSE
KIT
MX-USX1
SHARPDESK 1 LICENSE KIT
MX-USX5
SHARPDESK 5 LICENSE KIT
MX-UN10A
Sharp OSA Network Scanner
Tool 10 License Kit
MX-UN01A
Sharp OSA Network Scanner
Tool 1 License Kit
MX-UN05A
Sharp OSA Network Scanner
Tool 5 License Kit
MX-EC50
CARD SOLUTION KIT
MX-EB12
MIRRORING KIT
AR-SV1
STAMP CARTRIDGE
MX-SM10
EXPANSION MEMORY
BOARD
MX-SCX1
STAPLE CARTRIDGE
MX-AM10
WEB BROWSING EXPANSION
KIT
MX-KB11
KEYBOARD
MX-FR33U
DATA SECURITY KIT
MX-FR33
DATA SECURITY KIT
AR-SC2
STAPLE CARTRIDGE
AR-SC3
STAPLE CARTRIDGE
