[4] Error code table
G3 Transmission
Code Final received signal Error Condition (Receiver side)
0 Incomplete signal frame Cannot recognize bit stream after flag
1 NSF, DIS Cannot recognize DCS signal
Cannot recognize NSS signal
2 CFR Disconnects line during reception
3 FTT Disconnects line by fallback
4 MCF Disconnects line during reception of multi-page
Cannot recognize NSS, DCS signal in the case of mode change
5 PIP or PIN No response in receiver side to picture signal after no response in transmitter side to receive
TALK mode request
6 RTN or RTP Cannot recognize NSS, DCS signal after transmitting RTN or RTP signal.
7 No signal or DCN No response in receiver side or DCN signal received*
G3 Reception
Code Final received signal Error Condition (Transmitter side)
0 Imcomplete signal frame Cannot recognize bit stream after flag
1 NSS, DCS Cannot recognize CFR or FTT signal
Disconnects line during transmission
2 NSC, DTC Cannot recognize NSS signal
3 EOP Cannot recognize MCF, PIP, PIN, RTN, RTP signal
4 EOM Cannot recognize MCF, PIP, PIN, RTN, RTP signal in the case of mode change
5 MPS Cannot recognize MCF, PIP, PIN, RTN, RTP signal in the case of multi-page
6 PR1-Q Cannot recognize PIP, PIN signal in the case of TALK request
7 No signal or DCN No response in transmitter (cannot recognize DIS signal) or DCN signal received*
UX-177H
2 – 16
