Sharp UX-177 - Parts Guide

PARTS GUIDE
MODEL UX-177
UX-177H
1 Cabinet, etc.
2 Upper cabinet
3 Document guide upper
4 Drive unit
5 Optical unit
6 Packing material & Accessories
7 Control PWB unit
8 TEL-Liu PWB unit
9 Power supply PWB unit
10 CCD PWB unit
50 Hardware parts
Index
CONTENTS
Because parts marked with " " is indispensable for the machine safety maintenance and operation, it must be
replaced with the parts specific to the product specification.
