SFE-LC (IC8) terminal descriptions
Pin Name Pin No. I/O
Input
Type
Output
Type
Pin Description
(Active low signals have an "n" pin name ending.)
CPU Control Interface
MIRQn 135 I HU − Modem interrupt. (Hysteresis In, Internal Pullup.)
SYSCLK 133 I H − System clock. (Hysteresis In.)
TSTCLK 130 O − 3XC Test clock.
Bus Control Interface
A[19:0] [5:6][8:13]
[15:20][22:27]
O T 3XT Address bus (20-bit).
D[7:0] [136:139]
[141:144]
I/O T 3XT Data bus (8-bit).
RDn 128 O − 3XTT Read strobe.
WRn 127 O − 3XTT Write strobe.
ROMCSn 120 O − 2XT ROM chip select.
CS1n 122 O − 2XT I/O chip select.
CS0n 57 O − 2XTT SRAM chip select. (Battery powered.)
MCSn 121 O − 2XC Modem chip select.
SYNC 126 O − 2XC Indicates CPU op code fetch cycle (active high).
REGDMA 124 O − 3XC Indicates REGSEL cycle and DMA cycle.
WAITn 125 O − 3XC Indicates current TSTCLK cycle is a wait state or a halt state.
Prime Power Reset Logic and Test
DEBUGn 129 I HU − External non-maskable input (NMI).
RESETn 131 I/O HU 2XO XFC-B Reset.
TEST 58 I C − Sets Test mode (battery powered).
Battery Power Control and Reset Logic
XIN 59 I OSC − Crystal oscillator input pin.
XOUT 60 O − OSC Crystal oscillator output pin.
PWRDWNn 62 I H − Indicates loss of prime power (results in NMI).
BATRSTn 61 I H − Battery power reset input.
Scanner Interface
START 101 O − 2XS Scanner shift gate control.
CLK1 100 O − 2XS Scanner clock.
CLK1n 99 O − 2XS Scanner clock-inverted.
CLK2 98 O − 2XS Scanner reset gate control (or clock for CIS scanner).
VIDCTL[1:0] [97:96] O − 2XC Control for video preprocessing circuits.
Printer Interface
PCLK 29 O − 3XC Thermal Print Head (TPH) clock.
PDAT 30 O − 2XP Serial printing data (to TPH).
PLAT 31 O − 3XP TPH data latch.
STRB[3:0] [33:36] O − 1XP Strobe signals for the TPH.
STRBPOL 37 I C − Sets strobe polarity, active high/low.
