Sharp UX-177 - Page 81

1 Cabinet, etc.
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
CCNW-4587XH01 AL N C Speaker ass’y
2
CGERH2306XH02 AN N C Paper feed roller gear ass’y
3
CPNLH2371XH18 BM N D Upper cabinet ass’y
4
DCEKC787HXHZZ BY N E Control PWB unit(Within ROM)
5
GCABB2277XHPA AV N D Lower cabinet
6
GCOVA2370XHZA AN N C Rear cover
7
GCOVA2369XHZA AN N D Recording paper cover
8
GLEGG2063XHZZ AC N C Rubber leg
9
LBNDJ0002FCZZ AA C Band
10
LBSHP2082XHZZ AC N C Platen bearing
11
LFRM-2171XHZZ AL N C Head frame
12
PSPAZ2216XHZZ AC N C Cussion spacer
13
LPLTP2841XHZZ AH N C Platen plate
14
LSTPF2046XHZZ AF N C Panel unit stopper
15
MLEVP2235XHZZ AD N C Paper sensor lever
16
MLEVP2236XHZA AE N C Hook switch lever
17
MSPRC2884XHZZ AC N C Head pressure spring 2
18
MSPRC2832XHZZ AC N C Hopper spring
19
MSPRC2834XHZZ AD N C Pinch pressing spring 2
20
MSPRD2849XHZZ AD N C Paper sensor lever spring
21
MSPRD2874XHZZ AF N C Paper guide spring
22
RCORF2063XHZZ AF B Core
23
NGERH2329XHZZ AC N C Platen gear
24
NGERP2318XHZZ AD N C Pinion gear
25
NROLP2334XHZZ AE N C Pinch roller
26
PSHEZ3253XHZZ AC C Hopper sheet
27
NROLR2333XHZZ AP N C Paper feed roller
28
NROLR2353XHZZ AX N C Platen roller
29
NSFTZ2258XHZZ AF N C Pinch roller shaft
30
PGIDM2449XHZA AF N C Hopper guide, left
31
PGIDM2450XHZA AF N C Hopper guide, right
32
PGIDM2460XHZZ AD N C Head guide, right
33
PGIDM2461XHZZ AD N C Head guide, left
34
PGIDM2465XHZZ AT N C Recording paper guide
35
PGIDP2462XHZA AT N C Document guide lower
36
PSHEZ3031XHZZ AA C Jack sheet
37
PCUSS2098XHZZ AB N C Speaker cushion
38
QACCB7125SCZZ AZ B AC cord ass’y
39
QCNW-4590XHZZ AL N C Head cable
40
QCNW-4591XHZZ AE N C Head earth cable
41
QCNW-4672XHZA AF N C 10key cable
42
RCORF1030LCZZ AE B Core
43
MSPRC2886XHZZ AC C Head pressure spring
44
RCORF2103XHZZ AF N B Core
45
RDENT2102XHZZ BN N E Power supply PWB unit
46
RHEDZ2046XHZZ BT B Thermal head
47
DCEKL337BXH01 BK N E TEL-Liu PWB unit
48
LPLTP2839XHZZ AH N C Anti curl
49
MSPRT2853XHZZ AD N C Anti curl spring
50
NSFTZ2264XHZZ AL N C Anti curl shaft
52
PSHEZ3234SCZZ AC N C Head cover sheet
53
NGERH2331XHZZ AE N C Cutter gear ass’y
54
PCUT-2034SCZZ AU N C Cutter unit
55
PGIDM2463XHZZ AD N C Recording paper guide upper
56
PGIDM2464XHZZ AD N C Recording paper guide lower
57
PGIDM2466XHZZ AF N C Cutter guide
58
QCNW-4615XHZZ AE N C Sensor cable
59
QSW-M2238SCZZ AF N C Recording paper sensor
60
PTME-2050XHZZ AD N C Paper cover lock hook
61
LHLDW2160SCZZ AD C Cable clamp
62
MSPRB2883XHZZ AC C Platen spring
63
LBNDJ2006XHZZ AA C Band
64
PSPAG2222SCZZ AC N C Spacer
65
TLABS4052XHZZ AD N C BABT label
66
TLABH3841XHZZ AD N C Warning label
67
PSHEZ3269SCZZ AD N C Document guide sheet
68
PSHEZ3266SCZZ AD N C Paper guide sheet
69
LPLTM2835XHZZ AK C Shield plate
70
PSHEZ3248XHZZ AC C Insulation sheet
71
PSPAZ2213XHZZ AE C Spacer
72
PFLT-2006XHZZ AA C Sheet
73
TLABM3677XHZZ AD C Mercury label
74
CCNW-4592XH01 AQ C Panel cable
UX-177H
– 2 –
