Sharp UX-177 - Page 90

7 Control PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
321
RCRSP2080SCZZ AF B Crystal(24.00014MHz) [X1]
322
RCRSP2327RCZZ AD B Crystal(12MHz) [X2]
323
RCRSB0297AFZZ AD B Crystal(32.768KHz) [X3]
324
VHERD22FB3/-1 AC B Zener diode(RD22FB3) [ZD1]
(Unit)
901
DCEKC787HXHZZ BY N E Control PWB unit(Within ROM)
8 TEL-Liu PWB unit
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
1
VHVRA501PV6-1 AE N B Varistor(RA501PV6) [AR1]
2
VHVRA501PV6-1 AE B Varistor(RA501PV6) [AR2]
3
QCNW-4619XHZZ AE N C ARG cable [ARG]
4
RC-EZ2022SCZZ AB C Capacitor(10WV 47µF) [C1]
5
VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C2]
6
VCEAGA1HW105M AB C Capacitor(50WV 1.0µF) [C3]
7
VCEAGA1CW107M AC C Capacitor(16WV 100µF) [C4]
8
VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C5]
9
VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C6]
10
VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C7]
11
RC-FZ2012SCZZ AE C Capacitor(250WV 1.8µF) [C8]
12
VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C9]
13
VCEAGA1AW336M AA C Capacitor(10WV 33µF) [C10]
14
VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C11]
15
VCEAGA1HW335M AB C Capacitor(50WV 3.3µF) [C12]
16
VCEAGA1AW107M AB C Capacitor(10WV 100µF) [C13]
17
VCEAGA1HW105M AB C Capacitor(50WV 1.0µF) [C14]
18
VCEAGA1HW105M AB C Capacitor(50WV 1.0µF) [C15]
19
VCEAGA2AW474M AC C Capacitor(100WV 0.47µF) [C16]
20
VCQYNA1HM224K AC C Capacitor(50WV 0.22µF) [C17]
21
VCEAGA1HW225M AA C Capacitor(50WV 2.2µF) [C18]
22
VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C19]
23
VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C20]
24
VCEAGA1HW105M AB C Capacitor(50WV 1.0µF) [C21]
25
VCKYTV1HB561K AA C Capacitor(50WV 560PF) [C101]
26
VRS-TS2AD000J AA C Resistor(1/10W 0Ω ±5%) [C102]
27
VCKYTQ1EB224K AB C Capacitor(25WV 0.22µF) [C103]
28
VCKYTQ1HB563K AA C Capacitor(50WV 0.056µF) [C104]
29
VCKYTQ1HB473K AA C Capacitor(50WV 0.047µF) [C105]
30
VCKYTQ1HB104K AB C Capacitor(50WV 0.1µF) [C106]
31
VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C108]
32
VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C109]
33
VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C110]
34
VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C111]
35
VCKYTV1HB223K AA C Capacitor(50WV 0.022µF) [C113]
36
VCKYTV1HB472K AA C Capacitor(50WV 4700PF) [C114]
37
VCKYTV1HF223Z AA C Capacitor(50WV 0.022µF) [C116]
38
VCKYTV1HB102K AA C Capacitor(50WV 1000PF) [C117]
39
VCKYTQ1HB104K AB C Capacitor(50WV 0.1µF) [C118]
40
VCCCTV1HH101J AA C Capacitor(50WV 1000PF) [C119]
41
VCKYTV1HB562K AA C Capacitor(50WV 5600PF) [C120]
42
VCKYTV1HB183K AA C Capacitor(50WV 0.018µF) [C121]
43
VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C122]
44
VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C123]
45
VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C124]
46
VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C125]
47
VCKYTV1HB681K AA C Capacitor(50WV 680PF) [C131]
48
VCKYTV1HF223Z AA C Capacitor(50WV 0.022µF) [C132]
49
VCKYTV1HF223Z AA C Capacitor(50WV 0.022µF) [C133]
50
VCKYTV1HF223Z AA C Capacitor(50WV 0.022µF) [C134]
51
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C135]
52
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C136]
53
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C137]
54
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C138]
55
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C139]
56
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C140]
57
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C141]
58
VCKYTV1HB331K AA C Capacitor(50WV 330PF) [C142]
59
VCCCTV1HH300J AA C Capacitor(50WV 30PF) [C143]
60
VCCCTV1HH300J AA C Capacitor(50WV 30PF) [C144]
61
VCKYTV1HB103K AB C Capacitor(50WV 0.01µF) [C145]
62
VCKYTV1CF105Z AB C Capacitor(16WV 1.0µF) [C146]
63
RRLYZ3420SCZZ AN N B Relay(G6GN-2D) [CML]
64
QJAKZ2065SC0D AG C Jack [CNHJ]
65
QCNCW2500SC0H AF C Connector(12pin) [CNLIUA]
66
QCNCW2500SC1A AE C Connector(11pin) [CNLIUB]
UX-177H
– 11 –
