Sharp UX-40 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PA RT
RANK
DESCRIPTION
UX-40DE
FO-50DE
– 2 –
[1] Cabinet etc.
1 DCEKK201CFF01 N E Operation panel unit [40]
DCEKK201CFF02 N E Operation panel unit [50]
2 CCNW-212AXH01 AK N C Panel cable ass’y
5 MSPRC2954FFZZ N C Hopper spring
6 NGERP2318XHZZ AD C Pinion gear
7 PGIDM2560XHSA AC N C Hopper,guide,left [40]
PGIDM2560XHSC N C Hopper,guide,left [50]
8 PGIDM2561XHSA AC N C Hopper,guide,right [40]
PGIDM2561XHSC N C Hopper,guide,right [50]
9 PHOP-2104FFSA N C Hopper cover [40]
PHOP-2104FFSC N C Hopper cover [50]
11 QSW-M2296XHZZ AD B Door sensor
12 CCNW-215AFF01 N C Speaker ass’y
13 GCABB2343FFSA N D Lower cabinet [40]
GCABB2343FFSC N D Lower cabinet [50]
14 MSPRP3119XHZZ AC N C Panel lock lever spring
15 MSPRP3123XHZZ AC N C Speaker holder lever spring
16 DCEKL227CFF01 N E TEL/Liu PWB unit
!
17 GCASP2110XHSD AK N C PWB case,top [40]
!
GCASP2110XHSE AK N C PWB case,top [50]
!
18 GCASP2111XHSA AH N C PWB case,bottom [40]
!
GCASP2111XHSC AH N C PWB case,bottom [50]
19 MLEVP2320XHZZ AC N C Hook switch joint lever
!
20 QACCE2013BMZZ N B AC cord ass’y
!
21 RDENT2144XHZZ BA N E Power supply PWB unit
22 GDAI-2083FFZZ N C Paper support guide
23 MLEVP2316XHZZ AC N C Paper sensor lever
24 MSPRD3116FFZZ N C Paper sensor lever spring
27 PGIDM2563XHSA AE N C PO guide [40]
PGIDM2563XHSC AC N C PO guide [50]
28 LBSHP2112XHZZ AB N C Platen bearing
29 LFRM-2208FFZZ N C Head frame
30 LHLDZ2184XHZZ AC N C Head holder,left
31 LHLDZ2185XHZZ AC N C Head holder,right
33 MSPRC3112FFZZ N C Head spring 1
34 MSPRC3148FFZZ N C Head spring 2
36 NGERH2478XHZZ AB N C Platen gear
37 NROLR2425XHZZ AP N C Platen roller
39 QCNW-209AXHZZ AH N C Head cable
40 QCNW-210AXHZZ AC N C Head earth cable
41 RHEDZ2059XHZZ BF N B Thermal head
45 CPWBX3084FF01 N E Control PWB unit(Without ROM)
46 GDAI-2082XHSA AD N C Handset cover [40]
GDAI-2082XHSC N C Handset cover [50]
47 LSTPP2054XHZZ AC N C Panel stopper
49 MLEVP2319XHZZ AC N C Hook switch lever
52 PGIDM2566XHZZ AC N C Head guide
!
53 RCORF2064XHZZ AF B Core(TRA31)
54 HPNLH2392XHSV N D Decoration panel [40]
HPNLH2392XHS4 N D Decoration panel [50]
58 MLEVP2321XHZZ AN N C Release lever
B1 LX-BZ2138FFZZ N C Screw(2x6)
B3 XEBSD30P08000 AA C Screw(3x8)
B4 XBBSD30P06000 AA C Screw(3x6)
B5 XBPSN40P06K00 AA C Screw(4x6)
B7 XEBSD30P12000 AA C Screw(3x12)

Sharp UX-40 Specifications

General

Brand	Sharp
Model	UX-40
Category	Fax Machine
Language	English
