Sharp UX-B20 Service Manual

UX-B20U/UX-B20C/B25C
2 – 13
SW
NO.
DATA
NO.
ITEM
Switch setting and function Initial setting
Remarks
10U/C
SW
l
J1
1 Reserved 0
2 Reserved 0
3 Sender’s phone number setting Cannot change Change allowed 0
4 Reserved 0
5 Reserved 0
6 Summer time setting No Yes 1 OPTION
7
8
Ringer volume Off Low Middle High
1
0
OPTION
No. 70011
No. 80101
SW
l
J2
1
2
Speaker volume (3 stages) Low Low Middle High
1
0
OPTION
No. 10011
No. 20101
3 Reserved 0
4
5
Handset receiver volume Low Low Middle High
1
0
OPTION
No. 40011
No. 50101
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
l
J3
1 Reserved 0
2
3
4
Communication results printout
(Transaction report)
E/T/M Send
only
Always No print Err only
1
0
0
OPTION
No. 200001
No. 300110
No. 401010
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
l
K1
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
SW
l
L1
1 Reserved 0
2 Reserved 0
3 Reserved 0
4 Reserved 0
5 Cut off mode (COPY mode) Yes No 1 OPTION
6 A4 paper enable Enable Disable 0
7 LEGAL & LETTER paper enable Enable Disable 1
8 Reserved 0
SW
l
L2
1
2
Paper set size LETTER LEGAL A4
0
0
OPTION
No. 1 001
No. 2 010
3 Automatic reduce of receive Auto 100 % 1 OPTION
4 Reserved 0
5 Reserved 0
6 Reserved 0
7 Reserved 0
8 Reserved 0
