[2] Circuit description of control PWB
1. General description
Fig. 2 shows the functional blocks of the control PWB, which is com-
posed of 5 blocks.
2. Description of each block
2.1. Main control block
The main control block is composed of CONEXANT 1 chip fax engine
(SCE209L), FLASH (4Mbit), DRAM (16Mbit), ASIC (µPD65945).
Devices are connected to the bus to control the whole unit.
2.1.1 SCE209L (IC5): pin-176 QFP (FAX CONTROLLER)
1 chip fax engine has Internal Integrated Analog (CX06835) and Inter-
nal memory (SRAM : 32kbit).
2.1.2 PMC39LV040 (IC7): pin-32 TSOP (FLASH)
FLASH of 4Mbit equipped with software for the main CPU.
2.1.3 MSM51V4800E (IC1): pin-28 SOJ (DRAM)
• Image memory for recording process.
• Memory for recording pixel data without paper.
• Memory for system work and ECM receive buffer.
2.1.4 µPD65945 (IC4): pin-144 TSOP (ASIC)
ASIC between SCE209L and SPITFIRE.
It converts the resolution and the aspect ratio of the serial scanning
data sent by SCE209L and sends the converted data to Spitfire by par-
allel IF.
2.1.5 M12L16161A-7TG (IC3): pin-28 SOJ (DRAM)
Dedicated image buffer for ASIC (IC4).
2.2. IC5 (SCE209L) Hardware description
2.2.1 Integrated Controller (SCC)
The Controller contains an internal MC24 Processor with a 16-MB
address space and dedicated circuitry optimized for facsimile image
processing and monitoring and for thermal or thermal transfer printer
support. The CPU provides fast instruction (up to 10 MHz clock speed)
execution and memory efficient input/output bit manipulation. The
CPU connects to other internal functions over an 8-bit data bus and
24-bit address bus and dedicated control lines. The 24-bit external
address bus, 8-bit data bus, control, status and decoded chip select
signals support connection to external DRAM and FLASH memory.
2.2.2 DRAM Controller
The CX06835 includes a DRAM controller with signal and page mode
access support which supports fast, normal, or slow refresh time.
DRAM memory space is provided in one block up to 4 MB. A maxi-
mum of 4 MB of DRAM is supported. This space has a programmable
size and starting address. Refresh is performed automatically and is
supported in stand-by mode. CAS and RAS signal support is provided
for one-DRAM banks for both 4-bit and 8-bit organizations. Access
speeds from 50ns to 70ns can be supported.
2.2.3 DMA Channels
Six internal DMA channels support memory access for scanner, T.4/
T.6, and resolution conversion. DMA Channel 2 can be reprogrammed
for external access to thermal printing, thermal transfer, or plain paper
inkjet printing.
2.2.4 External RAM and ROM
Moveable and programmable size external SRAM memory of up to 1
MB, DRAM memory of up to 4 MB, and ROM of up to 2 MB can be
directly connected to the SCE209L. By using an external address
decoder, the size of SRAM and/or ROM can be extended. The ROM
stores all the program object code.
2.2.5 Flash Memory Controller
The SCE209L includes a flash memory controller that supports NOR,
NAND, and Serial NAND-type flash memory. The supported size of
NOR-type memory is up to 1 MB and the supported size of NAND-type
memory is unlimited.
2.2.6 Stepper Motor Control
Eight outputs are provided to external current drivers: four to the scan-
ner motor and four to the printer motor. The stepping patterns are pro-
grammable and selectable line times are supported. A time out circuit
controls the power control of the motors. The printer or scanner motor
outputs can be programmed as GPOs for applications using single
motor or paper printers.
2.2.7 T.4/T.6 Compression/Decompression
MH, MR and MMR compression and decompression are provided in
hardware. T.4 line lengths of up to 8192 pixels are supported. MMR
and Alternating Compression/Decompression (ACD) on a line by line
basis provide support for up to three independent compression and
decompression processes.
2.2.8 Bi-level Resolution Conversion
One independent programmable bi-level 1D-resolution conversion
block is provided to perform expansion or reduction on the T.4 decom-
pressed data and scan image data. Image expansion can be pro-
grammed up to 200% and reduction down to 33%. Vertical line O-Ring
and data output bit order reversal is also provided.
2.2.9 Printer IF
The Printer Interface provides a standard connection between the
SCE209L and a thermal printhead to support thermal printing or ther-
mal transfer. The thermal printer interface consists of programmable
data, latch, clock, and up to four strobe signals. Programmable timing
supports traditional thermal printers, as well as the latchless split mode
printers, and line lengths of up to 2048 pixels. Line times from 5 ms to
40 ms are supported. The SCE209L includes a thermal ADC (TADC)
function utilizing a D/A converter and a comparator to monitor the
printhead temperature. External terminating resistors must be sup-
plied; the values are determined by the specific printhead selected. As
an option, plain paper inkjet printing can be supported.
Fig. 2 Control PWB functional block diagram
(1) SCE209L
IA(CX06835)
MEMORY(SRAM)
(2) FLASH
(4) ASIC (5) DRAM
(3) DRAM
To Next Page
