Sharp UX-P200 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-P100U
UX-P200U
– 8 –
[6] Control PWB unit
81 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C189]
82 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C194]
83 VCCCCY1HH471J AA C Capacitor(50WV 470PF) [C199]
84 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C200]
85 QCNCM7014SC0G AB C Connector(7pin) [CNCIS]
86 QCNCM7014SC0B AD C Connector(2pin) [CNCSW]
87 QCNCM2508SC1B AF N C Connector(12pin) [CNLIUA]
88 QCNCM7014SC0F AB C Connector(6pin) [CNMT]
89 QCNCM7014SC1F AD C Connector(16pin) [CNPN]
90 QCNCM7014SC0C AA C Connector(3pin) [CNPRG]
91 QCNCM2638SC0F AE N C Connector(6pin) [CNPW]
92 QCNCM2401SC0B AA C Connector(2pin) [CNSP]
93 QCNCM7014SC1E AC C Connector(15pin) [CNTH]
94 VHDHRW0202B-1 AD B Diode(HRW0202B) [D100]
95 VHD1SS355//-1 AB B Diode(1SS355) [D101]
96 VHD1SS355//-1 AB B Diode(1SS355) [D102]
!
97 QFS-P2010SCZZ AD B IC protector(KAB2402) [FU100]
98 VHIF002/TA01B BN N B IC,EPROM(2MB)(TA01B) [IC1][P100]
99 VHIF002/TA02B BN N B IC,EPROM(2MB)(TA02B) [IC1][P200]
100 RH-IX2168SCZZ BB B IC(MSM51V4800E) [IC2]
101 VHISCE209//-1 BH N B IC(SCE209) [IC3]
102 VHINJM2113M-1 AG B IC(NJM2113M) [IC4]
103 VHIKID65001AP AE B IC(KID65001AP) [IC5]
104 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L100]
105 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L102]
106 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L103]
107 VRS-CY1JB150J AA C Resistor(1/16W 15Ω ±5%) [L104]
108 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L105]
109 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L106]
110 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [L107]
111 VSKTA1504GR-1 AC B Transistor(KTA1504GR) [Q100]
112 VSKRC106S//-1 AD B Transistor(KRC106S) [Q101]
113 VSKRC102S//-1 AB B Transistor(KRC102S) [Q102]
114 VSKRC102S//-1 AB B Transistor(KRC102S) [Q103]
115 VSSI4431DY+-1 AF B FET(SI4431DY) [Q107]
116 VSKRA102S//-1 AD N B Transistor(KRA102S) [Q108]
117 VSKRC102S//-1 AB B Transistor(KRC102S) [Q109]
118 VRS-HT3DA221J AB C Resistor(2W 220Ω ±5%) [R1]
119 VRS-CY1JB562J AA C Resistor(1/16W 5.6KΩ ±5%) [R100]
120 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R101]
121 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R102]
122 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R103]
123 VRS-CY1JB471J AA C Resistor(1/16W 470Ω ±5%) [R104]
124 VRS-CY1JB471J AA C Resistor(1/16W 470Ω ±5%) [R105]
125 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R107]
126 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R111]
127 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R112]
128 VRS-CY1JB512J AA C Resistor(1/16W 5.1KΩ ±5%) [R113]
129 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R114]
130 VRS-CY1JB203J AA C Resistor(1/16W 20KΩ ±5%) [R116]
131 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R117]
132 VRS-CY1JB124J AA C Resistor(1/16W 120KΩ ±5%) [R118]
133 VRS-CY1JB203J AA C Resistor(1/10W 20KΩ ±5%) [R119]
134 VRS-CY1JB224J AA C Resistor(1/16W 220KΩ ±5%) [R120]
135 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R121]
136 VRS-CY1JB151J AA C Resistor(1/16W 150Ω ±5%) [R124]
137 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R125]
138 VRS-CY1JB471J AA C Resistor(1/16W 470Ω ±5%) [R126]
139 VRS-CY1JB105J AA C Resistor(1/16W 1MΩ ±5%) [R127]
140 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R128]
141 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R129]
142 VRS-CY1JB121J AA C Resistor(1/16W 120Ω ±5%) [R130]
143 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R131]
144 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R132]
145 VRS-CY1JB104J AA C Resistor(1/16W 100KΩ ±5%) [R133]
146 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [R134]
147 VRS-CY1JB103J AA C Resistor(1/16W 10KΩ ±5%) [R135]
148 VRS-CY1JB474J AA C Resistor(1/16W 470KΩ ±5%) [R136]
149 VRS-CY1JB203J AA C Resistor(1/16W 20KΩ ±5%) [R137]
150 VRS-CY1JB224J AA C Resistor(1/16W 220KΩ ±5%) [R139]
151 VRS-CY1JB513J AA C Resistor(1/16W 51KΩ ±5%) [R140]
152 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R141]
153 VRS-CY1JB106J AA C Resistor(1/16W 10MΩ ±5%) [R142]
154 VRS-CY1JB104J AA C Resistor(1/16W 100KΩ ±5%) [R143]
155 VRS-CY1JB104J AA C Resistor(1/16W 100KΩ ±5%) [R144]
156 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [R145]
157 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R146]
158 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R147]
159 VRS-CY1JB203J AA C Resistor(1/16W 20KΩ ±5%) [R148]
160 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R149]
