Sharp UX-P200 - Interface PWB Unit; Operation Panel PWB Unit

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-P100U
UX-P200U
– 11 –
[8] Power supply PWB unit
54 0CBUEFE124DH/ AC N C Metal film resistor(2W 120KΩ ±5%) [R24]
55 0CBUEXEAG222/ AC N C Resistor(1/4W 2.2KΩ ±5%) [R27]
56 0CB829655049/ BF N B Transformer(PTTN126-KTT) [T1]
57 0CBUEZ0747ZZ/ AD N B Varistor(S07K175GA) [V1]
58 0CBUFBA222EQ/ AD N B Variable resistor(2.2KΩ) [VR1]
59 0CBUBXAD270A/ AD B Zener diode(RD27SB-T1) [ZD1]
60 0CBUBXAD4R3C/ AD B Zener diode(RD4.3SB2-T1) [ZD2]
61 0CBUBDBM300D/ AC B Zener diode(RD30FB3-T7) [ZD4]
62 0CBUBXAD6R2C/ AD B Zener diode(RD6.2SB-T1) [ZD5]
63 0CBUBDDH5R6K/ AG N B Zener diode(RD5.6FMB) [ZD8]
(Unit)
!
901 RDENT2171XHZZ BH N E Power supply PWB unit
[9] Operation panel PWB unit
1 QSW-K0005AWZZ AC C Tact switch [SW]
!
2 QSW-M2246AXZZ AH C FRSNS sensor [SW1]
!
3 QSW-M2294XHZZ AE C ORGSNS sensor [SW2]
(Unit)
901 DCEKP336CXH01 BD N E Operation panel PWB unit [P100]
DCEKP336CXH02 BD N E Operation panel PWB unit [P200]
[10] Interface PWB unit
1 QCNCM7014SC1F AD C Connector(16pin) [CNPN]
2 QCNCM7014SC1F AD C Connector(16pin) [CNPN-A]
(Unit)
901 DCEKP337CXH01 AF N E Interface PWB unit
