Sharp UX-P200 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-P100U
UX-P200U
– 10 –
[7] TEL/LIU PWB unit
50 VRD-HT2EY823J AA C Resistor(1/4W 82KΩ ±5%) [R17]
51 VRD-HT2EY101J AA C Resistor(1/4W 100Ω ±5%) [R18]
52 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R19]
53 VRD-HT2EY563J AA C Resistor(1/4W 56KΩ ±5%) [R20]
54 VRD-HT2EY393J AA C Resistor(1/4W 39KΩ ±5%) [R21]
55 VRD-HT2EY621J AA C Resistor(1/4W 620Ω ±5%) [R22]
56 VRD-HT2EY163J AA C Resistor(1/4W 16KΩ ±5%) [R24]
57 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R25]
58 VRD-HT2EY473J AA C Resistor(1/4W 47KΩ ±5%) [R26]
59 VRD-HT2EY223J AA C Resistor(1/4W 22KΩ ±5%) [R27]
60 VRD-HT2HY223J AA C Resistor(1/2W 22KΩ ±5%) [R28]
61 VRS-HT3AA510J AA C Resistor(1W 51Ω ±5%) [R29]
62 VRS-RE3AA122J AC C Resistor(1W 1.2KΩ ±5%) [R30]
63 QSW-Z2317XHZZ AF N C Hook switch [SW1]
!
64 RTRNI2171XHZZ AL N B Transformer(I2171) [T1]
65 VHVERZV5D471/ AC B Varistor(ERZV5D471) [VA1]
66 VHVERZV5D471/ AC B Varistor(ERZV5D471) [VA2]
67 VHEMTZJ100B-1 AC B Zener diode(MTZJ10B) [ZD1]
68 VHEMTZJ5R6B-1 AB B Zener diode(MTZJ5R6B) [ZD2]
69 VHEMTZJ100B-1 AC B Zener diode(MTZJ10B) [ZD3]
70 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD4]
71 VHEHZ2C1///-1 AA B Zener diode(HZ2C1) [ZD5]
72 VHEHZ27-1//-1 AB B Zener diode(HZ27) [ZD6]
(Unit)
901 DCEKL335CXH01 BB N E TEL/LIU PWB unit
[8] Power supply PWB unit
1 0CBUGFM224KR/ AF C Film capacitor(275WV 2.2µF) [C1]
2 0CBUGA0291ZZ/ AL N C Capacitor(200WV 220µF) [C2]
3 0CBUGCU102JC/ AF N C Ceramic capacitor(1KWV 1000PF) [C3]
4 0CBUGXGCF102/ AD C Capacitor(50WV 1000PF) [C4]
5 0CBUGXGCF152/ AF C Capacitor(50WV 1500PF) [C5]
6 0CBUEXCAP000/ AC N C Resistor(1/8W 0Ω ±5%) [C6]
7 0CBUGCM103BH/ AD N C Ceramic capacitor(125WV 0.01µF) [C7]
8 0CBUGA0292ZZ/ AL N C Capacitor(35WV 330µF) [C8]
9 0CBUGA0290ZZ/ AK N C Capacitor(16WV 330µF) [C10]
10 0CBUGXGFD104/ AD N C Capacitor(25WV 0.1µF) [C12]
11 0CBUGCS152AC/ AD C Ceramic capacitor(500WV 1500PF) [C13]
12 0CBUGCU472BW/ AD C Ceramic capacitor(1000WV 4700PF) [C23]
13 0CBUGXGDF271/ AD C Capacitor(50WV 270PF) [C24]
14 0CBUGCZ472HF/ AD N C Ceramic capacitor(125WV 4700PF) [C26]
15 0CBUGCZ472HF/ AD N C Ceramic capacitor(125WV 4700PF) [C27]
16 0CBUGCM103BH/ AD N C Ceramic capacitor(125WV 0.01µF) [C28]
17 0CBPKZ0194ZZ/ AC C Base post ass’y(2pin) [CNAC]
18 0CBPCZ0307ZZ/ AH N C Connector(6pin) [CNPS]
19 0CBUBC0125DK/ AD B Diode(ERA15-06) [D1]
20 0CBUBC0125DK/ AD B Diode(ERA15-06) [D2]
21 0CBUBC0125DK/ AD B Diode(ERA15-06) [D3]
22 0CBUBC0125DK/ AD B Diode(ERA15-06) [D4]
23 0CBUBY0020AK/ AD B Diode(1SS355TE) [D5]
24 0CBUBC0336AZ/ AL B Diode(S3L20U-4004P15) [D7]
25 0CBUBC0093AL/ AG N B Diode(ERA84-009) [D8]
26 0CBUBC0169CL/ AE B Diode(ERA22-06V3) [D9]
27 0CBPJCSX2501/ AH A Current fuse(2.5A/125V) [F1]
28 0CBPZZ0906ZZ/ AH A Circuit protect chip(4A/72V) [F3]
29 0CBBFZ89256Z/ AD C Beads core(BL02RN1) [FB2]
30 0CBBFZ89633Z/ AD C Beads inductor(BP53RB052025050) [FB3]
31 0CBUKZ0790ZZ/ AK C Filter(19mH/0.5A) [L1]
32 0CBUZZ0203ZZ/ AK N C Inductor(RS908) [L2]
33 0CBLRZ6803ZP/ AQ N C Heat sink [MT1]
34 0CBUDC0062MZ/ AG B Photo coupler(PS2501-1L) [PC1]
35 0CBUAG0225AZ/ AQ N B FET(FS7KM) [Q1]
36 0CBUAC0255AM/ AD B Transistor(2SC4115S) [Q2]
37 0CBUAC0264AK/ AD B Transistor(2SC1741AS) [Q3]
38 0CBUAC0034EL/ AD B Transistor(2SC1740S) [Q4]
39 0CBUEEC225CF/ AC C Resistor(1/2W 2.2MΩ ±5%) [R1]
40 0CBUEXJAH474/ AC N C Resistor(1/4W 470KΩ ±5%) [R2]
41 0CBUEXJAH474/ AC N C Resistor(1/4W 470KΩ ±5%) [R3]
42 0CBUEEB681CT/ AC C Resistor(1/8W 680Ω ±5%) [R4]
43 0CBUEXCAP272/ AC N C Resistor(1/8W 2.7KΩ ±5%) [R5]
44 0CBUEXCAP181/ AC N C Resistor(1/8W 180Ω ±5%) [R7]
45 0CBUEXCAP473/ AC N C Resistor(1/8W 47KΩ ±5%) [R8]
46 0CBUEXCAP470/ AC N C Resistor(1/8W 47Ω ±5%) [R9]
47 0CBUEFDR12DB/ AE C Metal film resistor(1W 0.12Ω ±5%) [R10]
48 0CBUEXCAP472/ AC N C Resistor(1/8W 4.7KΩ ±5%) [R13]
49 0CBUEXCAP102/ AC N C Resistor(1/8W 1KΩ ±5%) [R14]
50 0CBUEXCAP334/ AC N C Resistor(1/8W 330KΩ ±5%) [R15]
51 0CBUEXCAP103/ AC N C Resistor(1/8W 10KΩ ±5%) [R16]
52 0CBUEXCAP332/ AC N C Resistor(1/8W 3.3KΩ ±5%) [R17]
53 0CBUEXJAH332/ AC N C Resistor(1/4W 3.3KΩ ±5%) [R18]
