Sharp UX-P200 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-P100U
UX-P200U
– 7 –
[6] Control PWB unit
1 UBATL2049SCZZ AF B Battery(CR2032T23) [BAT1]
2 VCEAGA0JW227M AD C Capacitor(6.3WV 220µF) [C1]
3 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C2]
4 VCEAGA0JW227M AD C Capacitor(6.3WV 220µF) [C3]
5 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C4]
6 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C5]
7 VCEAGA1EW476M AA C Capacitor(25WV 47µF) [C6]
8 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C8]
9 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C9]
10 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C10]
11 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C100]
12 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C101]
13 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C102]
14 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C103]
15 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C104]
16 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C105]
17 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C107]
18 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C109]
19 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C110]
20 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C111]
21 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C112]
22 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C113]
23 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C114]
24 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C115]
25 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C116]
26 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C117]
27 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C118]
28 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C119]
29 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C120]
30 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C121]
31 VCCCCY1HH180J AA C Capacitor(50WV 18PF) [C122]
32 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C123]
33 VCKYCY1HB103K AA C Capacitor(50WV 0.01µF) [C126]
34 VCKYCY1HB472K AA C Capacitor(50WV 4700PF) [C127]
35 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C128]
36 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C129]
37 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C130]
38 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C131]
39 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C132]
40 VCCCCY1HH221J AA C Capacitor(50WV 220PF) [C133]
41 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C134]
42 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C135]
43 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C136]
44 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C137]
45 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C139]
46 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C140]
47 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C141]
48 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C142]
49 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C143]
50 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C144]
51 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C145]
52 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C146]
53 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C147]
54 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C148]
55 VCCCCY1HH220J AA C Capacitor(50WV 22PF) [C149]
56 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C154]
57 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C155]
58 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [C157]
59 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C158]
60 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C159]
61 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C160]
62 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C161]
63 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C162]
64 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C163]
65 VCKYCY1HF104Z AA C Capacitor(50WV 0.1µF) [C167]
66 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C168]
67 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C169]
68 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C171]
69 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C172]
70 VCKYCY1AF105Z AC C Capacitor(10WV 1µF) [C175]
71 VRS-CY1JB000J AA C Resistor(1/16W 0Ω ±5%) [C176]
72 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C177]
73 VCKYCY1CB104K AB C Capacitor(16WV 0.1µF) [C178]
74 VCKYCY1EF104Z AA C Capacitor(25WV 0.1µF) [C182]
75 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C183]
76 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C184]
77 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C185]
78 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C186]
79 VCCCCY1HH101J AA C Capacitor(50WV 100PF) [C187]
80 VCKYCY1HB102K AA C Capacitor(50WV 1000PF) [C188]
