Sharp UX-P200 Service Manual

NO.
PARTS CODE
PRICE
RANK
NEW
MARK
PART
RANK
DESCRIPTION
UX-P100U
UX-P200U
– 9 –
[6] Control PWB unit
161 VRS-CY1JB223J AA C Resistor(1/16W 22KΩ ±5%) [R151]
162 VRS-CY1JB222J AA C Resistor(1/16W 2.2KΩ ±5%) [R152]
163 VRS-CY1JB392J AA C Resistor(1/16W 3.9KΩ ±5%) [R154]
164 VRS-CY1JB105J AA C Resistor(1/16W 1MΩ ±5%) [R156]
165 VRS-CY1JB752J AA C Resistor(1/16W 7.5KΩ ±5%) [R157]
166 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R160]
167 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R161]
168 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R165]
169 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R166]
170 VRS-CY1JB393J AA C Resistor(1/16W 39KΩ ±5%) [R167]
171 VRS-CY1JB124J AA C Resistor(1/16W 120KΩ ±5%) [R168]
172 VRS-CY1JB102J AA C Resistor(1/16W 1KΩ ±5%) [R169]
173 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R170]
174 VRS-CY1JB151J AA C Resistor(1/16W 150Ω ±5%) [R171]
175 VRS-CY1JB151J AA C Resistor(1/16W 150Ω ±5%) [R172]
176 VRS-CY1JB101J AA C Resistor(1/16W 100Ω ±5%) [R174]
177 VRS-CY1JB271J AA C Resistor(1/16W 270Ω ±5%) [R175]
178 RR-TZ3018SCZZ AC B Block resistor(470Ωx4) [RA1]
179 RR-TZ3018SCZZ AC B Block resistor(470Ωx4) [RA2]
180 RR-TZ3018SCZZ AC B Block resistor(470Ωx4) [RA3]
181 RR-TZ3017SCZZ AC B Block resistor(270Ωx4) [RA4]
182 VHIS814A33AUC AH N B IC(S-814A33AUC-BCX-T2) [REG1]
183 RCRSP2176SCZZ AG N B Crystal(32.256MHz) [X1]
184 RCRSB0297AFZZ AD B Crystal(32.768kHz) [X2]
185 VHE1N4748A/-1 AC B Diode(1N4748A) [ZD1]
186 VHE02CZ180Y-1 AC B (02CZ180Y) [ZD100]
(Unit)
901 DCEKC182RXHZZ BR N E Control PWB unit(Within ROM) [P100]
DCEKC182RXHZA BR N E Control PWB unit(Within ROM) [P200]
[7] TEL/LIU PWB unit
1 VHVRA391PV6-1 AE B Varistor(RA-391P-V6-2) [AR1]
2 VCEAGA1HW106M AA C Capacitor(50WV 10µF) [C1]
3 VCKYPA1HB222K AA C Capacitor(50WV 2200PF) [C2]
4 VCKYPA1HB102K AA C Capacitor(50WV 1000PF) [C3]
5 VCEAGA1HW225M AA C Capacitor(50WV 2.2µF) [C4]
6 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C5]
7 VCEAGA1HW475M AA C Capacitor(50WV 4.7µF) [C6]
8 VCKYPA1HB102K AA C Capacitor(50WV 1000PF) [C7]
9 VCKYPA1HB221K AA C Capacitor(50WV 220PF) [C8]
10 VCKYPA1HB102K AA C Capacitor(50WV 1000PF) [C9]
11 VCKYPA1HB102K AA C Capacitor(50WV 1000PF) [C10]
12 VCEAGA1HW226M AB C Capacitor(50WV 22µF) [C11]
13 VCEAGA1HW107M AA C Capacitor(50WV 100µF) [C12]
14 VCKYPA1HB221K AA C Capacitor(50WV 220PF) [C13]
15 VCKYPA1HF223Z AA C Capacitor(50WV 0.022µF) [C14]
16 VCKYPA1HB221K AA C Capacitor(50WV 220PF) [C15]
17 VCKYPA1HB102K AA C Capacitor(50WV 1000PF) [C17]
18 VCKYPA1HB103K AA C Capacitor(50WV 0.01µF) [C18]
19 RC-FZ3024SCZZ AG C Capacitor(250WV 0.82µF) [C19]
20 RRLYD3433XHZZ AH B Relay(OUAZ-SH-124DZ) [CML]
21 QCNCW715MAFZZ AF N C Connector(12pin) [CNLIUA]
22 VHDDSS133//-1 AA B Diode(1SS133) [D1]
23 VHDDSS133//-1 AA B Diode(1SS133) [D2]
24 VHIKIA324P/-1 AF N B IC(KIA324P) [IC1]
25 QJAKZ2073SCFB AD C Jack [MJ1]
26 QJAKZ2079XH0D AD C Jack [MJTEL]
27 VHPTLP521-1BL AE B Photo coupler(TLP521) [PC1]
!
28 VHPSG206S//-1 AG B Photo transistor(SG206S) [PH1]
!
29 VHPSG206S//-1 AG B Photo transistor(SG206S) [PH2]
30 VSKRC106M//-1 AD N B Transistor(KRC106M) [Q1]
31 VSKRC106M//-1 AD N B Transistor(KRC106M) [Q2]
32 VSKTC3198GR-1 AD N B Transistor(KTC3198GR) [Q3]
33 VSKRC106M//-1 AD N B Transistor(KRC106M) [Q4]
34 VSKRA102M//-3 AD N B Transistor(KRA102M) [Q5]
35 VRD-HT2EY102J AA C Resistor(1/4W 1KΩ ±5%) [R1]
36 VRD-HT2EY273J AA C Resistor(1/4W 27KΩ ±5%) [R2]
37 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R3]
38 VRD-HT2EY152J AA C Resistor(1/4W 1.5KΩ ±5%) [R4]
39 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R5]
40 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R6]
41 VRD-HT2EY102J AA C Resistor(1/4W 1KΩ ±5%) [R7]
42 VRD-HT2EY224J AA C Resistor(1/4W 220KΩ ±5%) [R8]
43 VRD-HT2EY362J AA C Resistor(1/4W 3.6KΩ ±5%) [R9]
44 VRD-HT2EY133J AA C Resistor(1/4W 13KΩ ±5%) [R10]
45 VRD-HT2EY332J AA C Resistor(1/4W 3.3KΩ ±5%) [R11]
46 VRD-HT2EY133J AA C Resistor(1/4W 13KΩ ±5%) [R12]
47 VRD-HT2EY822J AA C Resistor(1/4W 8.2KΩ ±5%) [R13]
48 VRD-HT2EY202J AA C Resistor(1/4W 2.0KΩ ±5%) [R15]
49 VRD-HT2EY151J AA C Resistor(1/4W 150Ω ±5%) [R16]
