Operation References
Operation References
2
Lithium battery cover (p. 10)
Tripod socket*
Left view
Dioptre adjustment dial (p. 17)
Battery release (pp. 6, 10)
* When attaching a tripod
with a guide pin, do not
attach the pin to the bottom
of the camcorder.
LCD monitor
(p. 18)
DV terminal (pp. 64, 66)
DC IN jack (pp. 7, 8)
AV terminal
(pp. 27, 61, 62, 66)
Terminal cover
(pp. 27, 61, 62, 64, 66)
