Preparation
Preparation
10
Installing the Lithium
Batteries
Installing the Memory Battery
The supplied CR1216 type lithium battery is
used to store the memory of the date and
time settings.
1 Make sure that the Power switch is
set to OFF.
2 Open the LCD monitor to a 90° angle
to the camcorder body.
3 Slide the battery release in the
direction of the arrow, then take the
battery pack out.
4 Pull out the lithium battery cover in
the direction of the arrow.
5 Insert the CR1216 type lithium
battery into the compartment with the
H side of the battery facing out.
6 Close the lithium battery cover firmly
until it clicks into place.
Removing the Memory
Battery
Perform steps 1 to 4 above,
then lift out the battery by
using a pointed object such
as the tip of a ballpoint pen.
Battery release
Lithium
battery cover
CR1216 type
lithium battery
VL-Z300S/VL-Z100S-GB-005-019 04.2.12, 1:54 PM10
