Appendix
79
Specifications
Camcorder
Signal System: PAL standard
Recording System: 2 rotary heads, helical scanning system
Cassette: Digital VCR Mini DV video cassette
Recording/Playback Time: 90 minutes (DVM60, LP mode)
Tape Speed: SP mode: 18.831 mm/second
LP mode: 12.568 mm/second
Pickup Device:
1
⁄
6
" (4.2 mm, effective size: 4.5 mm) CCD image sensor
(with approx. 800,000 pixels including optical black,
effective pixels: 414,000 pixels)
Lens: 10K optical zoom lens (F1.8, f=3.8–38.0 mm)
Lens Filter Diameter: 30 mm
Monitor: 2.5" (6.4 cm) CGSilicon
Viewfinder: 0.16" LCD panel, slide type
Built-in microphone: Electret monaural microphone
Colour Temperature Compensation: Auto white balance with white balance lock, outdoor or
indoor
Minimum Illumination: 2 lux* (with gain-up, F1.8)
DV terminal: 4 pin connector (i.LINK)
Power Requirement: DC 7.4 V
Power Consumption: 3.4 W (during camera recording in Camera mode
using the viewfinder in Full Auto mode with the DIS
function on)
4.0 W (during camera recording in Camera mode
using the LCD monitor in Full Auto mode with the DIS
function on and backlight in normal mode)
Operating Temperature: 0°C to L40°C
Operating Humidity: 30% to 80%
Storage Temperature: +20°C to L60°C
Dimensions (WKHKD) (approx.): 82.9 mm K 82.2 mm K 100.8 mm
Weight (approx.): 470 g (without battery pack, lithium battery, video
cassette and lens cap)
AC Adapter (UADP-A053WJZZ)
Power Requirement: AC 110–240 V, 50/60 Hz
DC Output: 10 V
Dimensions (WKHKD) (approx.): 49.0 mm K 27.5 mm K 79.0 mm
Specifications are subject to change without notice.
*Minimum illumination: Since there is no widely accepted testing procedure for determining
minimum illumination capability, lux ratings are comparable only between
models from the same manufacturer.
