Sharp XV-Z12000 Service Manual

194
XV-Z12000
Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
OPTICS MECHANISM PARTS
6-1 9HN-3650-0510 J Body Ass’y DF
6-2 9HN-3623-0042 J Cover Ass’y AX
6-3 PLNS-A040WJZZ J Projection Lens DF
6-4 9HN-3623-0043 J Projection Lens Fixin Plate AR
Ass'y, x2
6-5 9HN-9670-03067 J Screw, x4 AC
6-6 9HN-3623-4171 J Color Wheel Cover 1 AX
6-7 9HN-3623-0044 J Color Wheel Cover 2 Ass’y BC
6-8 9HN-9739-03087 J Screw, x4 AB
6-9 9HN-3623-4173 J Dumpping Rubber A AV
6-10 9HN-3623-4174 J Dumpping Rubber B AS
6-11 9HN-3623-4175 J Spacer A, x3 AE
6-12 9HN-3623-4177 J Spacer B, x4 AE
6-13 9HN-9642-26107 J Screw, x3 AB
6-14 9HN-3623-4176 J Washer, x3 AC
6-15 9HN-9612-20807 J Screw, x4 AB
6-16 9HN-9716-02007 J Washer, x4 AC
6-17 9HN-3623-0045 J G7 Lens Ass’y BH
6-18 9HN-9762-20607 J Screw, x2 AB
6-19 9HN-3623-4152 J Color Wheel Sensor PWB BE
6-20 9HN-9670-02047 J Screw, x2 AD
6-21 9HN-9716-02007 J Washer, x2 AC
6-22 CMIR-A035WJ02 J Color Wheel CK
å 7 BQC-XVZ100005 J Lamp Unit CQ
7-1 CCASZA003WJ02 J Lamp Case (A) Ass’y AX
7-1-1 LHLDZ3058CEFW J Handle AE
7-1-2
Not Available - Lamp Case A —
7-1-3 PCOVZA008WJFW J Punching AF
7-1-4 PSLDPA012WJFW J Shield AM
7-1-5 TLABZA461WJZZ J Caution Label AE
7-2 CCASZA004WJ01 J Lamp Case (B) Ass’y AU
7-2-1 Not Available J Lamp Case B —
7-2-2 PSLDPA011WJFW J Shield B AM
å 7-3 RLMPFA006WJN1 J Lamp CL
7-4 LANGKA094WJFW J Reflection Plate Angle AM
7-5 LANGK0773CEFW J Lamp Plug Angle AE
7-6 XEBSD30P08000 J Screw, x5 AA
7-7 XESSF30P08000 J Screw, x3 AA
8-1 9HN-9670-03067 J Screw, x2 AC
8-2 9HN-9670-03107 J Screw AC
8-3 NFANS0029CEZZ J Exhaust Fan BC
8-4 PSPAZA178WJZZ J Exhaust Fan Spacer, x3 AC
8-5 PSPAGA036WJZZ J Exhaust Fan Bush, x3 AE
8-6 LX-EZ3011CEFD J Screw, x3 AC
8-7 LANGK0783CEFW J Color Wheel Fan Angle AH
8-8 NFANSA013WJ00 J Color Wheel Fan AW
8-9 XBPSD30P30JS0 J Screw, x2 AB
8-10 PDUC-0158CEKZ J Lamp Duct AM
8-11 XEBSD30P08000 J Screw, x7 AA
8-12 LANGKA113WJFW J Socket Angle AF
8-13 XBPSD30P10JS0 J Screw, x2 AA
8-14 9HN-3623-0760 J Lamp Box Ass'y CC
8-16 9HN-3650-0570 J Lens + Illumination Ass'y EA
8-17 9HN-3650-0580 J CW Holder Ass'y CP
