Adjustment buttons
('/"/\/|)
Select menu items and other
settings.
INPUT button
Switch input mode 1, 2, 3, 4,
5 or DIGITAL.
ZOOM/FOCUS button
Adjust the projected image
size or adjust the focus.
Temperature warning
indicator
Lamp indicator
Power indicator
Remote control sensor
HEIGHT ADJUST button
Front adjustment foot
(on the bottom of
the projector)
MENU button
Display adjustment and
setting screens.
ENTER button
Set items selected or
adjusted on the menu.
UNDO button
Undo an operation or
returning to the previous
display.
STANDBY button
Put the projector into standby
mode.
RESIZE button
Switch the picture display
(STRETCH, SIDE BAR, etc.).
ON button
Turn the power on.
Projector
• Attaching the lens cap
Push the lens cap on until it clicks
into position.
• Removing the lens cap
Pull the lens cap directly outward.
Top View
Front View
