Sharp XV-Z2000

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
109
XV-Z2000
DT-400
DUNTKC754WEF0
FRONT-R/C UNIT
CAPACITORS
C1551 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1552 VCEAPF1CW107MY J 100 16V Electrolytic AC
RESISTORS
R1551 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R1552 VRS-TX2HF220JY J 22 1/2W Metal Oxide AB
MISCELLANEOUS PARTS
P1551 QPLGN0565FJZZY J Plug, 3-pin(RA) AD
RMC1551 RRMCUA027WJZZ J R/C Receiver AK
SLD1551 PSLDC0002SEFN J R/C Shield AC
INTEGRATED CIRCUITS
IC9102 RH-iXB194WJN1Q J IC AU
IC9201 VHiPQ018EZ5-1Y J PQ018EZ5MZP AF
IC9202 VHiTCDCR83D-1Y J CDCR83DBQR AR
IC9301 RH-iXA384WJN1Q J 2503253-003 BR
IC9401 VHiSH6742C+-1Q J SH6742CFA0PAG BD
IC9402 VHiLVC1G07C-1Y J SN74LVC1G07 AE
Note: When replace the following parts, it becomes PWB
replacement correspondece.
IC9101 — – DDP1010P —
IC9203 — – K4R271669F-TCS —
TRANSISTORS
Q9401 VSTPC8209++-1Y J TPC8209 AE
Q9402 VSTPC8209++-1Y J TPC8209 AE
Q9403 VSTPC8209++-1Y J TPC8209 AE
DIODES
D9201 VHDBAS316//-1Y J Diode AB
D9301 VHDSFPB76//2EY J Diode AD
D9302 VHDSFPB76//2EY J Diode AD
D9304 RH-EX1398CEZZY J Zener Diode, 8.2V AB
D9401 VHDBAT54SW+-1Y J Diode AC
D9402 VHDSFPA73//2EY J Diode AD
D9404 VHDBAT54SW+-1Y J Diode AC
D9405 VHDBAT54SW+-1Y J Diode AC
D9406 VHDBAT54SW+-1Y J Diode AC
D9407 VHDBAT54SW+-1Y J Diode AC
D9408 VHDBAT54SW+-1Y J Diode AC
D9409 RH-EX1013GEZZY J Zener Diode, 13V AD
PACKAGED CIRCUITS
X9101 RCRUAA041WJZZY J Crystal, 100MHz AN
COILS
L9301 RCiLP0325TAZZY J Peaking Coil AD
L9302 RCiLP0325TAZZY J Peaking Coil AD
CAPACITORS
C9100 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9101 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9102 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9103 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9104 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9105 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9106 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9107 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9109 VCCCCY1HH680JY J 68p 50V Ceramic AA
C9110 VCEAPF1CW106MY J 10 16V Electrolytic AB
C9111 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9112 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9113 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9114 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9117 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9118 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9121 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9124 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9126 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9129 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9130 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9133 VCCCCY1HH270JY J 27p 50V Ceramic AA
C9134 VCCCCY1HH270JY J 27p 50V Ceramic AA
C9137 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9140 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9141 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9144 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9149 VCEAPF1CW476MY J 47 16V Electrolytic AC
C9150 VCAAPE0GJ157MY J 150 4V Electrolytic AE
C9152 VCKYCY1EB104KY J 0.1 25V Ceramic AB
C9153 VCKYCY1EB104KY J 0.1 25V Ceramic AB
DUNTKC757WEF0
FORMATTER UNIT
CAPACITORS
C1501 VCKYCY1EF104ZY J 0.1 25V Ceramic AA
C1502 VCEAPF1CW107MY J 100 16V Electrolytic AC
RESISTORS
R1501 VRS-CY1JF471JY J 470 1/16W Metal Oxide AA
R1502 VRS-TX2HF220JY J 22 1/2W Metal Oxide AB
MISCELLANEOUS PARTS
P1501 QPLGN0565FJZZY J Plug, 3-pin(RB) AD
RMC1501 RRMCUA027WJZZ J R/C Receiver AK
SLD1501 PSLDC0002SEFN J R/C Shield AC
DUNTKC755WEF0
REAR-R/C UNIT
