Sharp XV-Z2000 Service Manual

33
XV-Z2000
DT-400
TROUBLESHOOTING TABLE
Checking the basic operation
Does the power LED light up or flash in
red or green?
Go to "Checking the power supply system"
and "Checking the power unit".
Does the set function with its keys or the
remote controller?
Go to "Checking the peripheral circuits of
the microprocessor".
Does the cooling fan rotate, and the lamp
turn on?
Go to "Checking the lamp light-up".
Is the user menu displayed?
Go to "Checking the peripheral circuits of
the formatter".
Does the analog RGB input function
normally?
Go to "Checking the RGB input".
Does the component input function
normally?
Go to "Checking the component".
Does the VIDEO input function normally?
Go to "
Checking of
VIDEO input ".
Does the DVI input function normally?
Check the DVI circuit and its peripheral
circuits.
Does the RS-232C function?
Go to "Checking RS-232C".
Does the autofocus function?
Go to "Checking the IRIS, FOCUS and
ZOOM motors".
End.
NO
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
YES

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
