Sharp XV-Z2000 Service Manual

Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
111
XV-Z2000
DT-400
DUNTKC757WEF0
FORMATTER UNIT (Continued)
R9138 VRS-CJ1JF132JY J 1.3k 1/16W Metal Oxide AA
R9139 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9140 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9141 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R9148 VRS-CH1JF102JY J 1k 1/16W Metal Oxide AA
R9149 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9150 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R9151 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R9152 VRS-CH1JF101JY J 100 1/16W Metal Oxide AA
R9154 VRS-CJ1JF101JY J 100 1/16W Metal Oxide AA
R9201 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9203 VRS-CY1JF560FY J 56 1/16W Metal Oxide AA
R9204 VRS-CY1JF111FY J 110 1/16W Metal Oxide AA
R9205 VRS-CY1JF111FY J 110 1/16W Metal Oxide AA
R9206 VRS-CY1JF560FY J 56 1/16W Metal Oxide AA
R9208 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R9209 VRS-CY1JF111FY J 110 1/16W Metal Oxide AA
R9210 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9211 VRS-CY1JF121FY J 120 1/16W Metal Oxide AA
R9212 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9213 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9214 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9215 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9216 VRK-CD1JJ390FY J 39 1/16W Metal Compo. AC
R9217 VRK-CD1JJ390FY J 39 1/16W Metal Compo. AC
R9218 VRK-CD1JJ390FY J 39 1/16W Metal Compo. AC
R9219 VRS-CY1JF390FY J 39 1/16W Metal Oxide AA
R9312 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9315 VRS-CJ1JF102JY J 1k 1/16W Metal Oxide AA
R9316 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9317 VRS-CY1JF103JY J 10k 1/16W Metal Oxide AA
R9401 RR-SZ0090CEZZY J 2.74k 1/10W Metal Oxide AA
R9402 RR-SZ0089CEZZY J 2.26k 1/10W Metal Oxide AA
R9403 VRS-CY1JF154JY J 150k 1/16W Metal Oxide AA
R9404 VRS-CY1JF332JY J 3.3k 1/16W Metal Oxide AA
R9405 VRS-TV1JD301JY J 300 1/10W Metal Oxide AA
R9406 VRS-CH1JF332JY J 3.3k 1/16W Metal Oxide AA
R9410 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9411 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9412 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9413 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9414 VRS-CY1JF302JY J 3.0k 1/16W Metal Oxide AA
R9415 VRS-TQ2BD101JY J 100 1/8W Metal Oxide AA
R9416 VRS-CY1JF106JY J 10M 1/16W Metal Oxide AA
R9417 VRS-CY1JF106JY J 10M 1/16W Metal Oxide AA
R9418 VRS-TQ2BD101JY J 100 1/8W Metal Oxide AA
R9419 VRS-CY1JF106JY J 10M 1/16W Metal Oxide AA
R9420 VRS-TQ2BD101JY J 100 1/8W Metal Oxide AA
R9421 VRS-TW2ED1R0JY J 1 1/4W Metal Oxide AB
R9422 VRS-TW2ED1R0JY J 1 1/4W Metal Oxide AB
R9423 VRS-TW2ED1R0JY J 1 1/4W Metal Oxide AB
R9426 VRS-CY1JF102JY J 1k 1/16W Metal Oxide AA
R9501 VRS-CY1JF330FY J 33 1/16W Metal Oxide AA
R9502 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R9504 VRS-CH1JF000JY J 0 1/16W Metal Oxide AA
R9508 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
R9509 VRS-CH1JF000JY J 0 1/16W Metal Oxide AA
R9513 VRS-CY1JF000JY J 0 1/16W Metal Oxide AA
SWITCH
S9101 QSW-S0203TAZZY J Slide Switch AD
MISCELLANEOUS PARTS
FB9007 RBLN-0209TAZZY J Ferrite Bead AB
FB9008 RBLN-0209TAZZY J Ferrite Bead AB
FB9009 RBLN-0209TAZZY J Ferrite Bead AB
FB9011 RBLN-0209TAZZY J Ferrite Bead AB
FB9101 RBLN-0209TAZZY J Ferrite Bead AB
FB9102 RBLN-0209TAZZY J Ferrite Bead AB
FB9103 RBLN-0253TAZZY J Ferrite Bead AA
FB9104 RBLN-0253TAZZY J Ferrite Bead AA
FB9201 RBLN-0253TAZZY J Ferrite Bead AA
FB9301 RBLN-0253TAZZY J Ferrite Bead AA
FB9401 RBLN-0210TAZZY J Ferrite Bead AB
FB9502 RBLN-0210TAZZY J Ferrite Bead AB
P9101 QEARBA011WJFMY J Earth Contact AE
P9102 QEARBA011WJFMY J Earth Contact AE
SC9001 QCNCM0039CEZZY J Socket, 12-pin AM
LANGTA160WJFW J PWB Fixing Angle, x2 AC
LX-BZA057WJFN J Screw, x2 AB

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
