Ref. No. Part No. ★ Description Code Ref. No. Part No. ★ Description Code
117
XV-Z2000
DT-400
OPTICAL MECHANISM PARTS
4 CCHSKA018WJ11 J Optical Mechanism Ass'y ED
4-1 LCHSKA018WJFW J Frame BL
4-2 PLNS-A054WJZZ J Projection Lens CN
4-3 CFiLWA081WJ01 J Color Wheel CC
4-4 LANGKA291WJFW J C/W Angle AM
4-5 LANGKA404WJFW J Sensor Bracket AH
4-6 LANGKA407WJFW J Hold Plate AX
4-7 LANGKA408WJFW J Frame Plate AX
4-8 LHLDZA389WJFW J LH Holder AQ
4-9 LHLDZA517WJFW J Mirror Holder C AX
4-10 LHLDZA518WJFW J FL Holder BB
4-11 LX-AZA001WJ00 J Screw, x4 AC
4-12 LX-BZA090WJF9 J Screw, x8 AX
4-13 LX-EZA019WJFN J Screw, x3 AD
4-14 LX-WZA026WJFN J Washer, Mirror Holder AX
4-15 MSPRCA057WJZZ J Spring BA
4-16 MSPRPA041WJFW J FL Spring AT
4-17 NFANRA034WJZZ J Exhaust Fan 2 BG
4-18 NFANRA035WJZZ J Exhaust Fan 1 BG
4-19 NFANSA017WJZZ J Lamp Fan BG
4-20 PCOVMA018WJFW J Dust Cover B AK
4-21 PCOVZA054WJFW J Frame Cover L AZ
4-22 PCOVZA055WJFW J C/W Cover AW
4-23 PCOVZA040WJKZ J Lamp House BG
4-24 PCOVZA044WJFW J Frame Plate AM
4-25 PCOVZA049WJKZ J Exhaust Fan Sheet AV
4-26 PCOVZA050WJFW J Spring, Lamp Duct B AK
4-27 PDUC-A050WJKZ J Exhaust Duct BB
4-28 PDUC-A051WJKZ J Lamp Duct B AQ
4-29 PDUC-A055WJKZ J Lamp EX Duct AR
4-30 CFiLWA082WJ01 J UV Mirror Ass'y BD
4-31 PLNS-A047WJZZ J Field Lens BK
4-32 CLNS-A052WJ01 J Rod Ass'y BV
4-33 CLNS-A048WJ01 J Lens Ass'y BQ
4-34 CMiR-A053WJ01 J Mirror Ass'y BF
4-35 PSLDHA031WJFW J Heat Shield for Lamp House AK
4-36 PSLDPA022WJFW J Flame,AP AK
4-37 PSLDPA026WJFW J FL Blind AR
4-38 PSLDPA025WJFW J DMD Aperture AN
4-39 PSLDPA035WJFW J Blind A AM
4-40 PSPAGA245WJZZ J Dumper Gum BC
4-41 PSPAGA246WJZZ J Spacer, x8 AY
4-42 PSPAZA511WJZZ J Ring Bush, x3 AP
4-43 PSPAZA584WJZZ J FL Packing D AS
4-44 PSPAZA589WJZZ J FL Packing C AK
4-45 PSPAZA590WJZZ J Dust Cover AW
4-46 PSPAZA603WJZZ J Blind Seel, x2 AF
4-48 RH-HXA005WJZZ J Thermal Sensor AK
4-49 QCNW-C720WJQZ J Photo Sensor cable AM
4-50 QCNW-D074WJZZ J Thermal Fuse AR
4-52 RUNTKA091WJZZ J Photo Sensor Unit AZ
4-53 XASSN20P06000 J Screw AD
4-54 XBPSN20P04J00 J Screw, x6 AD
4-55 XBPSN20P06J00 J Screw, x2 AD
4-56 XBPSN25P04JS0 J Screw AD
4-57 XBPSN25P10JS0 J Screw, x7 AD
4-58 XBPSN30P06000 J Screw, x3 AA
4-59 XBPSN30P35JS0 J Screw, x2 AD
4-60 XEBSN20P04000 J Screw, x2 AB
4-61 XEBSN30P08000 J Screw, x2 AA
4-62 XSBSN14P03000 J Screw, x3 AD
4-63 XSBSN20P04000 J Screw, x2 AD
4-64 XSPSN17P02500 J Screw, x2 AD
4-65 XSPSN20P02000 J Screw, x2 AC
4-66 XSPSN20P04000 J Screw, x19 AC
4-67 XSSSN20P07000 J Screw, x2 AD
4-68 XWHUW40-03000 J C/W Washer AK
4-69 QCNW-A635WJZZ J Connecting Cord AK
4-70 LHLDWA097WJZZ J Wire Holder AG
4-71 PSLDPA024WJFW J Light Shielding Panel-B AH
4-72 XBPSN20P10J00 J Screw AC
4-73 XBPSN25P06J00 J Screw AD
4-74 RCORFA008WJZZ J Ferrite Core AH
4-75 LX-EZA018WJFN J Screw, x4 AC
4-76 PCOVPA024WJSA J Focus Ring AY
4-77 RMOTBA005WJZZ J Focus/ Zoom Motor BS
4-78 CMOTBA011WJ01 J Aperture Ass'y BH
5 AN-K2LP – Lamp Unit (Option) —
24 DUNTKC757WEF0 J FORMATTER Unit CL
34 LHLDZA440WJFW J Backer Plate AM
38 MSPRPA048WJFW J Stud Spring, x2 AK
39 NSFTZA107WJFW J Shaft Screw, x2 AF
42 PRDARA138WJFW J Heat Sink AX
43 PRDARA137WJFW J Stud AK
44 PSHEGA035WJKZ J Thermal Pad AG
48 LX-WZA027WJFW J Washer, x2 AB
49 PSPAZA539WJZZ J Kapton Insulator AF
55 QSOCZA085WJZZ J Socket for C-Spring BA
56 RDMDPA015WJZZQ J DMD 0.7 XGA ES
58 XBPSN30P08JS0 J Screw, x2 AB
59 XBPSN30P14JS0 J Screw, x2 AB
