Sharp XV-Z2000 Service Manual

No. Adjusting point Adjusting conditions Adjusting procedure
27
XV-Z2000
DT-400
3-3 B-Bright / B-
Contrast
1. Group: AD
Subject: B-BRIGHT
(Black level)
B-CONTRAST
(White level)
2. Feed the window pattern
signal containing 91%
(0.64Vp-p) B signal and
0% level.
(Process/Gamma interac-
tion)
(SVGA or XGA)
Input 5 RGB input
1. Observe the 0% window pattern chromaticity on
CA100.
2. Starting with a bit dropout screen, vary the B-
Bright setting until the bright blue "y" setting turns
toward the black tone and stays there. Now raise
the setting by one point and adjust to the point
where the first bit dropout is encountered (the
setting changes over 5/1000).
3. Observe the 91% G signal chromaticity on CA100.
4. Starting with a bit dropout screen, vary the B-
Contrast setting until the bright blue "y" setting
turns toward the black tone and stays there. Now
raise the setting by one point and adjust to the
point where the first bit dropout is encountered
(the setting changes over 5/1000).
4-1 DTV Bright/
Contrast
Adjustment
1. Group: DTV
Subject: BRIGHT
(Black level)
CONTRAST
(White level)
1. Check the fixed value.
Contrast: 5
Bright: 55
4-2 DTV R-Bright/
Contrast
Adjustment
1. Group: DTV
Subject: R-BRIGHT
(Black level)
R-CONTRAST
(White level)
(Process/GAMMA interac-
tion Input5 Color differ-
ence input)
1. Observe the 0%black window pattern chroma-
ticity on CA100.
2. Starting with a bit dropout screen, vary the Bright
setting until the bright red "x" setting turns to-
ward the black tone and stays there. Now raise
the setting by one point and adjust to the point
where the first bit dropout is encountered (the
setting changes over 5/1000).
3. Observe the 100% W window pattern chromatic-
ity on CA100.
4. Starting with a bit dropout screen, vary the Con-
trast setting until the bright red "x" setting turns
toward the black tone and stays there. Now raise
the setting by one point and adjust to the point
where the first bit dropout is encountered (the
setting changes over 5/1000).
4-3 DTV G-Bright/
Contrast
Adjustment
1. Group: DTV
Subject:G-BRIGHT
(Black level)
G-CONTRAST
(White level)
(Process/GAMMA interac-
tion Input5 Color differ-
ence input)
1. Observe the 0%black window pattern chroma-
ticity on CA100.
2. Starting with a bit dropout screen, vary the Bright
setting until the bright green "y" setting turns
toward the black tone and stays there. Now raise
the setting by one point and adjust to the point
where the first bit dropout is encountered (the
setting changes over 5/1000).
3. Observe the 100% W window pattern chromatic-
ity on CA100.
4. Starting with a bit dropout screen, vary the Con-
trast setting until the bright green "y" setting turns
toward the black tone and stays there. Now raise
the setting by one point and adjust to the point
where the first bit dropout is encountered (the
setting changes over 5/1000).

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
