Sharp XV-Z2000 Service Manual

31
XV-Z2000
DT-400
Calling and quitting the process mode with the control keys on this model.
∗ Although it is possible for the process OUT to exit using the process menu, the IN/OUT toggle command is also
available considering the existing specification.
1. Calling and quitting
With the menu not displayed, press the "'", "'", """, """, "|", "\" and "ENTER" keys on main unit.
2. Others
Press the S2002 process key (toggle) on the main PWB to call and quit the process menu.
Note: When adjusting in the process mode, set a signal with a vertical frequency of 60 Hz or no signal. (May not be
properly adjusted with other signals.)
» Adjustment mode process menu
Adjustment mode process menu 1
* Adjust only the shaded items below.
Adjustment Process Menu
First layer DTV VERSION
DVD SS
VIDEO TEMP
AD OPTION
DLP PATTERN
VIDEO1 LAMP
PIXEL LINE
Pedestal EXIT
second layer Initial Value
DTV Contrast 5
Tint 8
Color 4
Sharpness 1
Bright 55
R-Bright 20
G-Bright 20
B-Bright 20
R-Contrast 120
G-Contrast 120
B-Contrast 120
EXIT
DVD Contrast 5
Tint 4
Color 5
Sharpness 1
CTi-Level 1
LTi-Level 0
CB-Offset 7
CR-Offset 7
Bright 55
B-DRIVE 41
R-DRIVE 41
EXIT
VIDEO Contrast 5
N-Tint 7
P-Tint 4
S-Tint 4
N-Color 7
P-Color 4
S-Color 7
Sharpness 2
CTi-Level 1
LTi-Level 0
CB-Offset 7
CR-Offset 7
Bright 55
B-DRIVE 41
R-DRIVE 41
EXIT

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
