Sharp XV-Z2000 Service Manual

35
XV-Z2000
DT-400
NO
YES
NO
YES
NO
YES
NO
YES
NO
YES
NO
NO
ABNORMAL
YES
YES
Checking the power unit
Is each connector of the power unit
fully inserted?
Securely insert the connectors.
Is the lamp door closed completely?
Fix the lamp door with screws.
Is the bimetal broken?
Replace the bimetal switch or restore
by pressing the red button.
Is AC voltage applied to both AC input
ends of DB701?
Replace F701. If other parts are
damaged, replace them.
Is DC voltage of approx. 6.25V
outputted to both ends of C726?
Check D707 and the peripheral circuits
of IC702 on the primary side. If
defective, replace them.
Is DC voltage of approx. 370V
outputted to the cathode of D701?
Replace the subunit or check the
primary side circuit.
if defective, replace them.
Replace the ballast power supply.
Is the specified voltage outputted to
each output terminal of EA701?
Check the secondary-side circuits of
T701. If defective, replace them.
Check the PWB circuits on each output
side.

Sharp XV-Z2000 Specifications

General

Projection distance	2.6 - 3.9 m
Contrast ratio (typical)	2500:1
Screen size compatibility	40 - 200 \
Projector native resolution	SXGA (1280x1024)
Lamp type	SHP
Lamp power	275 W
Light source type	Lamp
Service life of light source	3000 h
Video in	XGA, Mac 19” (in intelligent compression), SVGA/VGA, Mac 16”/13”
I/O ports	2x component, 1x RCA video, 1x S-video, DVI-I (analogue component, digital & analogue RGB) x 1
Dimensions (WxDxH)	310 x 287 x 104 mm
Power requirements	100-240V AC, 50/60Hz
Power consumption (typical)	360 W
Market positioning	Home cinema

Weight and Dimensions

Weight	4300 g
